Crawler Bulldozer Shantui 260HP SD26 Bulldozer with Ripper
Acntruck Automobile Sales (Shanghai) Co., Ltd.- Type：Universal Type
- Transmission：Hydraulic Transmission
- Walking Mode：Crawler
- Load and Unload Method：Front Discharge
- Engine Power：147~515kw
- Certification：ISO9001: 2000
Base Info
- Model NO.：SD26
- Condition：New
- Color：Yellow
- Operating Weight (Kg)：24700kg
- Ground Pressure (Kpa)：66
- Engine Model：Weichai Wp12
- Rated Power/Rated Speed (Kw/Rpm)：206,1800
- Center Distance of Track (mm)：2000
- Width of Track Shoes (mm)：560
- Specification：5495*3725*3402
- HS Code：8429521200
- Production Capacity：1000,PCS
Description
Basic Info.
Model NO. SD26 Condition New Color Yellow Operating Weight (Kg) 24700kg Ground Pressure (Kpa) 66 Engine Model Weichai Wp12 Rated Power/Rated Speed (Kw/Rpm) 206/1800 Center Distance of Track (mm) 2000 Width of Track Shoes (mm) 560 Specification 5495*3725*3402 HS Code 8429521200 Production Capacity 1000/PCSProduct Description
Crawler Bulldozer Shantui 260HP SD26 Bulldozer with RipperFeatures:
1. The structural parts inherit the excellent quality of Shantui mature products.
2. The electric harnesses adopt corrugated pipes for protection and deconcentrators for branching, featuring high protection grade.
3. The openable large-space side hoods make the repairs and maintenance easier.
4. All lubricating and maintenance points of machine are directed to the outer side of machine body to achieve convenient and rapid maintenances.
| Parameter name | SD26 | SD26E(LONG TRACK) | SD26F(FOREST LOGGING) | SD26S(LGP) |
| Performance parameters | ||||
| Operating weight (Kg) | 23400 | 24600 | 24700 | 25700 |
| Ground pressure (kPa) | 77 | 72 | 66 | 41 |
| Engine | ||||
| Engine model | WEICHAI WP12 | WEICHAI WP12 | WEICHAI WP12 | WEICHAI WP12 |
| Rated power/rated speed (kW/rpm) | 206/1800 | 206/1800 | 206/1800 | 206/1800 |
| Overall dimensions | ||||
| Overall dimensions of machine (mm) | 5495*3725*3402 | 5495*3725*3402 | 5495*3725*3402 | 6225*4365*3402 |
| Driving performance | ||||
| Forward speed (km/h) | F1: 0-3.8 F2:0-6.8 F3:0-11.7 | F1: 0-3.8 F2:0-6.8 F3:0-11.7 | F1: 0-3.8 F2:0-6.8 F3:0-11.7 | F1: 0-3.8 F2:0-6.8 F3:0-11.7 |
| Reversing speed (km/h) | R1:0-4.5 R2:0-8.1 R3:0-13.9 | R1:0-4.5 R2:0-8.1 R3:0-13.9 | R1:0-4.5 R2:0-8.1 R3:0-13.9 | R1:0-4.5 R2:0-8.1 R3:0-13.9 |
| Chassis System | ||||
| Center distance of track (mm) | 2000 | 2000 | 2000 | 2250 |
| Width of track shoes (mm) | 560 | 560 | 560 | 910 |
| Ground length(mm) | 2730 | 3050 | 2730 | 3480 |
| Tank capacity | ||||
| Fuel tank (L) | 450 | 450 | 450 | 450 |
| Working device | ||||
| Blade type | Straight-tilt | Straight-tilt | Straight-tilt | Straight-tilt |
| Ripper type | Single shank/3 shanks | Single shank/3 shanks | Single shank/3 shanks | -- |
| Ripping depth (mm) | 695/666 | 695/666 | 695/666 | -- |
