• Model NO.：SR13D
• Travel Speed：35cm,s
• Centrifugal Force：30.5KN
• Certification：CE, RoHS
• Condition：New
• Hydraulic Cylinder Brand：China
• Unique Selling Point：High Operating Efficiency
• Transport Package：Nude Package, Attached Parts and Tools Into Standa
• Specification：10.3X2.5X3.9
• Trademark：SHAN-TUI
• Origin：China
• HS Code：3005909000
• Production Capacity：1000

Basic Info.

Model NO. SR13D Travel Speed 35cm/s Centrifugal Force 30.5KN Certification CE, RoHS Condition New Hydraulic Cylinder Brand China Unique Selling Point High Operating Efficiency Transport Package Nude Package, Attached Parts and Tools Into Standa Specification 10.3X2.5X3.9 Trademark SHAN-TUI Origin China HS Code 3005909000 Production Capacity 1000

Product Description

SHANTUI Double Road roller 13t SR13D mini compactor machine

Product Description
SR13D Double-Drum Road Roller
SR13D new generation high-frequency electronically controlled double-drum vibratory road roller adopts the modular frame structure and the inclined drum support,
featuring prominent quality and high efficiency. This product is applicable for the road base layer and medium and small filling projects and is one ideal machine for pavement of concrete roads.
It can work with spreader to sufficiently play the comprehensive advantages of complete equipment set.

Technical Features
The imported U.S. QSB4.5 engine features strong power, stable and reliable performances, and good fuel economy. With the application of constant speed control,
the engine can automatically adjust to idling state under non-working condition to save fuel. The temperature controlled fan design and the load-sensing system technology save the fuel cost for the user.
The vibratory drums adopt the uniform amplitude design, in which the vibration edge and the drive edge are arranged in staggered manner to realize more uniform compaction and smoother road.
The design of flexible startup and flexible stop can prevent the occurrence of soil sediment during startup and stop of machine.
The speed control knob is equipped to set up the working speed and impact cycles so that every working cycle is working under step frequency to realize better compacting uniformity.
The water tank up to 1,100L capacity remarkably prolongs the working time, with two filler ports and two outlet ports.
SR13D-3 vibration system includes two frequencies, namely 51Hz and 67Hz, and its working efficiency is promoted by >34% than that of traditional machines.
The 0.3mm low vibration amplitude is especially suitable for compacting thin layers and bridge surface layers and the 0.8mm high vibration amplitude can be used for compacting thick layers, featuring high compacting efficiency.
The electrohydraulic control adopts the internally supplied units and the advanced matching design and sophisticated control technology guarantee reasonable vibration start and stop times and good compacting uniformity.
The standard driver shelter features beautiful modeling and excellent comfort and visual field.
The slidable and 180º rotatable control console can be adjusted depending on the operator's needs.
The high resolution display screen can clearly display the information for the water level, oil level, water temperature, oil temperature, frequency, and impact cycles to provide a comfortable environment for the operations.
SR13D-3 provides good visual field and driving comfort for the accurate operations.
The gull-wing engine hood design is adopted. When the gull-wing hoods on two sides are opened, the engine and hydraulic pump are completely revealed in the operation range
so that the maintenances points can be fulfilled on the ground. The merely 40L hydraulic oil tank can save the maintenance cost for the user.
The water sprinkling system is located on the lower portion of the machine body to ease the cleaning of water sprinkler filter and nozzle and the water drainage in cold days.


Parameter name	SR13D
Performance parameters
Operating weight (Kg)	13000
Exciting force (KN)	150/86
Vibration frequency (Hz)	48/50
Nominal amplitude (mm)	0.66/0.36
Ground pressure (KPa)	-
Gradeability (%)	30
Engine
Engine model	BF4M2012
Rated power/rated speed (kW/rpm)	98/2300
Overall dimensions
Overall dimensions of machine (mm)	5775*2370*3133
Driving performance
Forward speed (km/h)	F1:0-10
Reversing speed (km/h)	R1:0-10
Chassis System
Wheelbase (mm)	-
Tank capacity
Fuel tank (L)	300
Working device
Compacting width(mm)	2130
