• Model NO.：9035E
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Operating Weight：3500kg
• Bucket Width：350mm
• Walking Speed：3.7 Km,H
• Operation Hydraulic Pressure：16 MPa
• Power：7.5,2, 400 Kw,Min-1
• Engine：Yanmar
• Max. Digging Height：5385 mm
• Max. Digging Depth：3085 mm
• Max. Digging Radius：2416 mm
• Transport Package：Nude
• Specification：3575*1050*2347
• Trademark：YANMA
• Origin：China
• HS Code：8429521200
• Production Capacity：100units Per Month

Operating weight with cab3980 kgOperating weight with canopy3860 kgEngine power21.2 kW (28.4 hp) @ 2400 rpmBucket capacity0.06-0.11 m³Maximum travel speed (High)4.6 km/hMaximum travel speed (Low)2.7 km/hMaximum swing speed10 rpmArm breakout force20 kNBucket breakout force30 kNShipping length4810 / 4860 mmShipping width1700 mmShipping height2500 mmTrack shoe width (std)300 mmBoom2450 mmArm1320 / 1700 mmDigging reach5385 / 5715 mmDigging reach on ground5270 / 5603 mmDigging depth3085 / 3440 mmVertical wall digging depth2503 / 2713 mmCutting height4710 / 4843 mmDumping height3310 / 3463 mmMinimum front swing radius2416 / 2413 mmDozer-up370 mmDozer-down390 mmSwing boom left rotation70 °Swing boom right rotation50 °ModelYanmar 3TNV88-BPLYEmissionEU Stage IIIASystem maximum flow92.4 L/min ( 24 gal/min)System pressure24.5 MPa
