• Model NO.：L938F
• Type：Medium-sized Loader
• Bucket Capacity：2m3
• Rated Power：92kw
• Load Capacity：3t
• Machine Weight：12500kg
• Transport Package：Nude Package
• Specification：7710*3450*2880mm
• Trademark：SDLG
• Origin：China
• HS Code：8429510000
• Production Capacity：100units Per Month

Overall dimensionL*W*H5790*2140*2920mmWheel base2260mmMin. ground clearance290mmMax. dumping height2510mmDumping distance3200mmDumping angle45wheel tread1630mmsteering angle35horizontal crossing radius5082mmMin. turning radius4460mmOverall parametersBacket capacity1.0(1.0-1,4)m3Rated load1800kgoperating weight6700kgMax. tractive force56kNMax. breakout force58kNTipping load36kNEngineModelYN4EL089-33CRTypeWater-cooled, four stroke, direct injectionRated power65.5kWRated speed2200r/minEngine displacement3760mlClylinder bore/stroke4Max. torque340N.mEmission standardGB20891-2014 China Phase IIIMin. fuel-consume ratio210g/kw.hTransmission systemTorgue convertersingle-stage three-element hydraulic torque converterTransmission typeFixed shaft power shift+high/low speedGearsForward 2 reverse 2Hydraulic system of working deviceTypeHydraulic pilot controltotal time<=9.1sBrake systemService brake typeAir over hydraulic disc brakeParking brake typeManual control internal expanding shoe brakeSteering systemTypeLoad sensing full hydraulic articulated steeringSystem pressure12 MpaFill capacityFuel120LHydraulic oil100LEngine7.5LTransmission20LDrive axleForward 10L+ reverse 10LBraking system4L
