• Model NO.：924E
• Size：Large-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Operating Weight：24500kg
• Bucket Width：700mm
• Walking Speed：5.1 Km,H
• Operation Hydraulic Pressure：34.3 MPa
• Power：7.5,2, 400 Kw,Min-1
• Engine：Cummins
• Max. Digging Height：9870mm
• Max. Digging Depth：6562 mm
• Max. Digging Radius：3090mm
• Transport Package：Nude
• Specification：9570*3090*3140
• Trademark：CUMMINS
• Origin：China
• HS Code：8429521200
• Production Capacity：100units Per Month

Operating weight with cab24500 kgEngine power124 kW (166 hp) @ 2050 rpmBucket capacity1.0 m³Maximum travel speed (High)5.3 km/hMaximum travel speed (Low)3.0 km/hMaximum swing speed11.4 rpmArm breakout force97 kNArm breakout force Power boost105 kNBucket breakout force140 kNBucket breakout force Power boost152.5 kNShipping length9570 mmShipping width3090 mmShipping height3140 mmTrack shoe width (std)700 mmBoom5710 mmArm2915 mmDigging reach9870 mmDigging reach on ground9685 mmDigging depth6562 mmVertical wall digging depth5080 mmCutting height9945 mmDumping height7170 mmMinimum front swing radius3090 mmModelCummins QSB6.7EmissionEU Stage IV / EPA Tier 4FSystem maximum flow2×224 L/min (2x59 gal/min)System pressure34.3 MPa
