• Model NO.：L953F
• Type：Medium-sized Loader
• Bucket Capacity：3m3
• Rated Power：162kw
• Load Capacity：5t
• Machine Weight：16930kg
• Transport Package：Nude Package
• Specification：7710*3450*2880mm
• Trademark：SDLG
• Origin：China
• HS Code：8429510000
• Production Capacity：100units Per Month

Overall dimensionL*W*H8050*3024*3423mmWheel base3000mmMin. ground clearance534mmMax. dumping height3040mmDumping distance1150mmDumping angle45wheel tread2250mmsteering angle35horizontal crossing radius6995mmMin. turning radius6040mmOverall parametersBacket capacity3.0m3(optional 2.4-4.5)Rated load5000kgoperating weight17100kgMax. tractive force160kNMax. breakout force170kNTipping load110kNEngineModelWD10G220E23TypeInline, watercooled, dry cylinder liner, direct injectionRated power162kWRated speed2000r/minEngine displacement9726mlMax. torque980N.mEmission standardGB 20891-2007(China Phase II)Min. fuel-consume ratio215g/kw.hTransmission systemTorgue convertersingle-stage four-element
double-turbine hydraulic torque converterTransmission typePlanetary power shiftGearsForward 2 reverse 1Hydraulic system of working deviceTypePilot controltotal time10sBrake systemService brake typeAir over hydraulic disc typeParking brake typeElectric pneumatic internal expansion shoe typeSteering systemTypeLoad sensing full hydraulic articulated steeringSystem pressure16 MpaFill capacityFuel260LHydraulic oil240LEngine20LTransmission45LDrive axleForward 26L+ reverse 26LBraking system4L
