Hydraulic Horizontal Directional Drilling Rig with 68t Thrust Force

Wuhan Kudat Industry & Trade Co., Ltd.
  • Type：Drill
  • Pressure Pile Driver Type：Hydraulic Pile Driver
  • Pile Hammer Type：Hydraulic Hammer
  • Power Source：Diesel
  • Motor Power：225kw
  • Noise：With Noise

Base Info

  • Model NO.：KD60
  • Certification：ISO 9001:2000
  • Condition：New
  • Pulling Back/Thrust Force：68t
  • Thrust Force：680kn
  • Pullback Force：680kn
  • Feed Travel：6500-7000 mm
  • Drilling Angle：8-18 0
  • Dimension：9000*2750*2800 mm
  • Weight：22000 Kg
  • Mud Pump：Bwf-600
  • Max. Discharge：600 L,Min
  • Peak Pressure：8 MPa
  • Transport Package：Naked Packing
  • Specification：Pulling ,thrust force: 68 T
  • Trademark：KUDAT
  • Origin：China
  • HS Code：8430412900
  • Production Capacity：1000PCS,Year

Description

Power of Engine WD615 Styre 225 KWMax push capacity680 kNMax pull capacity680 kNRated torque
 Low27000 N.mHigh135 N.m
Rated speed
 Low0-45 r/minHigh0-90 r/minFeed travel6500-7000 mmDrilling angle8-18 0Move ModePropelled with Track AssembliesDimension L×W×H9000×2750×2800 mmWeight22000 kgMud PumpModelBWF-600Max. Discharge600 L/minPeak Pressure8 MPaDrilling tools and auxiliary systemSpecification of Rod102×5000 mmGuide Bit170(230) mmReamer400;500;600;720;830;900;1000,1100Rotary connecting swivel80THydraulic Horizontal Directional Drilling Rig with 68t Thrust ForceHydraulic Horizontal Directional Drilling Rig with 68t Thrust ForceHydraulic Horizontal Directional Drilling Rig with 68t Thrust ForceHydraulic Horizontal Directional Drilling Rig with 68t Thrust Force
