Engineering & Construction Machinery

Home > Product > Loader

4WD Front Wheel Loaders

Wuhan Kudat Industry & Trade Co., Ltd.
  • Certification：TUV, UL, ISO, RoHS, CE, ISO9001: 2000
  • Condition：New
  • Rated Load：<1t
  • Transmission：Hydraulic - Mechanical
  • Load and Unload Mode：Front Discharge
  • Walking Mode：Wheeled

Base Info

  • Model NO.：ZL08F
  • Type：Small Loader
  • Rate Load (Kg)：1000
  • Bucket Capacity (M3)：0.5
  • Min. Turning Radius (mm)：4200
  • Dump Clearance(mm)：2450
  • Dump Reach (mm)：900
  • Max. Breakout Force (Kn)：32
  • Drive Means：Four Wheel Drive
  • Operating Weight (Kg)：2880
  • Overall Dimensions (Length*Width*Height)：4900*1600*2570
  • Engine Rated Power (Kw)：26
  • Transport Package：Nude Packing
  • Specification：CE
  • Trademark：Kudat
  • Origin：China
  • HS Code：8429
  • Production Capacity：500units,Month

Description

Main Technical Parameter of ZL10BItemParameterRated load (kg)1000Bucket capacity (m 3 )0.5Wheel tread (mm)1320Wheel base (mm)2020Min turning radius (mm)4200Min ground clearance (mm)220Dumping height (mm)2450Corresponding dumping reach (mm)1050Lifting time (s)4.5Hydraulic cycle time (s)9Maximum excavating force (KN)24Drive modeFour are DriveMachine weight (kg)2880Overall dimensions (mm) (Length*width*height)4930*1600*2570Engine modelChangchaiZN485QRated power of engine (kw)26Rated speed of engine (rpm)2200
