• Model NO.：KD28U
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Color：Blue
• Function：Earthmoving
• Operating Weight(Kg)：3200kg
• Standard Bucket Capacity(M3)：0.11cbm
• Height/ Width/ Length(mm)：2540,1745,4950
• Bucket Digging Force(Kn)：26.4
• Max Traction(Kn)：33.5
• Swing Angle(°)：50(Rh) 85(Lh)
• Travelling Speed(Km/H)：2.7,4.2 Km,H
• Max Gradeability(°)：30
• Transport Package：Bulk
• Specification：CE
• Trademark：kudat
• Origin：China
• Production Capacity：500PCS,Year

 Operating Weight(kg)3200Standard bucket Capacity(m3)0.11Height/ width/ length(mm)2540/1745/4950Bucket digging force(kN)26.4Max Traction(kN)33.5Swing angle(°)50(RH) 85(LH)Travelling speed(km/h)2.7/4.2 km/hMax gradeability(°)30Ground pressure(kPa) Swing speed(rpm)10.5ENGINEKubota D1803-M-DI-E3B-SWD-1Type4 cycle, 4 cylinder, water cooled, vertical overhead valveBattery(V/AH)12 / 80Max power(kW/rpm)23.8 / 2300Fuel tank(L)38HYDRAULIC SYSTEM Main Pumpstwo variable pumps and one gear pumpWorking pressure(Mpa)22.5Flow(L/min)2*36Gear pump Pressure(Mpa)20.5Flow(L/min)28Froe runner pump Pressure(Mpa)3.5Flow(L/min)8Hydraulic Oil Tank Capacity(L)43
