• Model NO.：SEM822LGP
• Condition：New
• Color：Yellow
• Product Name：(Sem822LGP)220HP Sem Bulldozer
• Operating Weight：23680kg
• Model：Weichai Wd12g240e26
• Track Shoe Width：560mm
• Maximum Digging Depth of Ripper：650mm
• Maximum Clearance Under Tip：640mm
• Max.Output Rimpull：350kn
• Max. Blade Digging Depth：563mm
• Max.Blade Lift Ground Clearance：1140mm
• Blade Height：1511 mm
• Transport Package：Nude Package
• Specification：7461*3782*3364mm
• Trademark：SEM
• Origin：China
• HS Code：8429521200
• Production Capacity：1000pieces,Year

Model

SEM 822Operating Weight 23680kgGround Pressure70 kPaGround Clearance394 mmMax. Slope30^°EngineModelWeichai WD12G240E26Flywheel Power 162Kw/220HpWork ToolBlade Type SU Blade Capacity6.4 m³(U 7.5 m³)Blade Width 3720 mm(U 4015 mm)Blade Height 1511 mmMax.Blade Lift Ground Clearance1140mmMax. Blade Digging Depth563mmMax.Output Rimpull350KNMaximum Clearance Under Tip640mmMaximum Digging Depth Of Ripper650mmPowertrainType Electric control,Dual-path,Hydrostatic Drive Travel Speed-F/R0-11.5km/hr(Infinitely Variable Speed Control) Streeing & Brake

Hydrostatic Streeing,Wet,Multiple-Disc Brakes

Minimum Streeing Radius4225mmUndercarrigeTrack Shoe Width560mmTrack Shoe Quantity40 pieceLength Of Track On Ground2948mmTrack Gauge2000mmTrack Roller Quantity 7/SideCarrier Roller Quantity2/SideHydraulic System    TypePilot ControlImplement Hydraulic System Pressure19 MpaService Refill Capacities Cooling System45LHrdrostatic Oil62LImplement Oil110LFuel460LPivot Shaft Case(Eash side)0.8L
