• Model NO.：XG4161T
• Engine Power：74~147kw
• Certification：ISO9001: 2000
• Condition：New
• Color：Yellow
• Rated Speed：1850rpm
• Rated Power：131kw
• Engine：Weichai
• Blade Height：1168mm
• Blade Width：3416mm
• Ground Pressure：0.069
• Minimum Turning Radius：3100
• Min. Ground Clearance：400
• Productivity：247
• Transport Package：Nude
• Specification：6447*3416*3060 mm
• Trademark：XGMA
• Origin：China
• HS Code：84291190
• Production Capacity：1000 Units,Year

Basic Info.

Model NO. XG4161T Engine Power 74~147kw Certification ISO9001: 2000 Condition New Color Yellow Rated Speed 1850rpm Rated Power 131kw Engine Weichai Blade Height 1168mm Blade Width 3416mm Ground Pressure 0.069 Minimum Turning Radius 3100 Min. Ground Clearance 400 Productivity 247 Transport Package Nude Specification 6447*3416*3060 mm Trademark XGMA Origin China HS Code 84291190 Production Capacity 1000 Units/Year

Product Description

Good quality XGMA 180HP XG4161T Bulldozer

1.A diesel engine with turbocharger and fuel-feeding system of PT pump is adopted as the power supplier for the machine, with its characteristics of low fuel consumption, high power performance and large torque reserve.

2.The diesel engine matches very well with the hydraulic torque converter and the transmission system, making a wide rotational speed range for machine traveling in high efficiency. Output power can be achieved perfectly, with the control of shifting on the transmission gearbox.

3.A hydraulic drive system is adopted for the working device, with its characteristics of simple structure, flexibility and reliability.

4.The hydraulic-assisting mode is adopted in the control system, making the machine can be operated easily.

5.A mode of hanging balance beam is adopted in the traveling system, making the machine works well in rugged areas system to ensure machine performance in the harsh environment of the rainforest.

6.Using a special cooling Mechanical winch and hydraulic winch can choose to adapt to different operational requirements.




Performance Parameters

DescriptionUnitXG4161TXG4221T
EngineModeltypeWeichai WD10G178E25 NT855-C280Rated speedrpm18501800Rated powerkW131162Fuel consumptiong/kW.h223212Travel
       SpeedForwardIkm/h0~3.80~3.6IIkm/h0~6.60~6.5IIIkm/h0~10.60~11.2ReverseIkm/h0~4.90~4.3IIkm/h0~8.50~7.7IIIkm/h0~13.60~13.2Work
       EquipmentBlade heightmm11681315Blade widthmm34163725Shoe widthmm510610Ground PressureMpa0.0690.077Minimum turning radiusmm31003300Maximum climbing ability°3030SpecificationMin. ground clearancemm400405Operating weightkg2010027836Productivitym3/h247330Cable  WinchType YJ14YTJM20Rope diameter×lengthmmΦ26×70000Φ28×70000pullkN136350Rope working speed ( outermost layer )m/min0-200-15.9System pressure Hydraulic separation combinedHydraulic separation combinedWeight 3000kg3000kgOverall  Dimensions
       (LxWxH)Basicmm6447x3416x30606887x3725x3454
