Dh24-B2 240HP 23850kg Bulldozer
Acntruck Automobile Sales (Shanghai) Co., Ltd.- Type：Universal Type
- Transmission：Hydraulic Transmission
- Walking Mode：Crawler
- Load and Unload Method：Front Discharge
- Engine Power：147~515kw
- Certification：CE, ISO9001: 2000
Base Info
- Model NO.：DH24-B2
- Condition：New
- Color：Yellow
- Transport Package：Nude Package
- Specification：5495*3725*3402
- Trademark：Shantui
- Origin：China
- HS Code：8429119000
- Production Capacity：50000PCS,Year
Description
Basic Info.
Model NO. DH24-B2 Condition New Color Yellow Transport Package Nude Package Specification 5495*3725*3402 Trademark Shantui Origin China HS Code 8429119000 Production Capacity 50000PCS/YearProduct Description
Power SystemWeichai mechanical engine conforms to the China-II non-road machinery emission regulation, featuring high intelligence and efficiency, simple structure, high parts interchangeability, and low maintenance cost.
The intelligent match technology can achieve best working efficiency and most reasonable fuel economy, with the composite fuel consumption reduced by 10~15%.
| Parameter name | DH24-B2 XL | DH24-B2 LGP |
| Performance parameters | ||
| Operating weight (Kg) | 23850 | 26450 |
| Ground pressure (kPa) | 68.4 | 40.9 |
| Engine | ||
| Engine model | Weichai WD12G250E202 | Weichai WD12G250E202 |
| Rated power/rated speed (kW/rpm) | 185/1900 | 185/1900 |
| Overall dimensions | ||
| Overall dimensions of machine (mm) | 6095*3640*3192 | 6255*4365*3228 |
| Driving performance | ||
| Forward speed (km/h) | 0-11 | 0-11 |
| Reversing speed (km/h) | 0-11 | 0-11 |
