180kw Str23 Trimming Bulldozer
Acntruck Automobile Sales (Shanghai) Co., Ltd.- Type：Universal Type
- Transmission：Hydraulic Transmission
- Walking Mode：Crawler
- Load and Unload Method：Front Discharge
- Engine Power：147~515kw
- Certification：CE, ISO9001: 2000
Base Info
- Model NO.：STR23
- Condition：New
- Color：Yellow
- Transport Package：Nude Package
- Specification：5495*3725*3402
- Trademark：Shantui
- Origin：China
- HS Code：8429119000
- Production Capacity：50000PCS,Year
Description
Basic Info.
Model NO. STR23 Condition New Color Yellow Transport Package Nude Package Specification 5495*3725*3402 Trademark Shantui Origin China HS Code 8429119000 Production Capacity 50000PCS/YearProduct Description
Power System
The installed QSNT-C235 electronically controlled engine conforms to the China-III non-road machinery emission regulation, featuring strong power, high efficiency and energy-saving, and low maintenance cost.
The rated power reaches 180kW, featuring high torque reserve coefficient.
The radially sealed intake system is applied to effectively prolong the engine life.
| Parameter name | STR23(Trimming bulldozer, ore version) |
| Performance parameters | |
| Operating weight (Kg) | 25540 |
| Ground pressure (kPa) | 69 |
| Engine | |
| Engine model | QSNT |
| Rated power/rated speed (kW/rpm) | 179/2000 |
| Overall dimensions | |
| Overall dimensions of machine (mm) | 5535 |
| Driving performance | |
| Forward speed (km/h) | F1:0-3.8 F2:0-6.8 F3:0-13.8 |
| Reversing speed (km/h) | R1:0-4.9 R2:0-8.5 R3:0-14.3 |
| Chassis System | |
| Center distance of track (mm) | 2000 |
| Width of track shoes (mm) | 560 |
| Ground length(mm) | 2840 |
| Tank capacity | |
| Fuel tank (L) | 485 |
| Working device | |
| Blade type | Trimming blade |
| Digging depth (mm) | 740 |
| Ripper type | - |
| Ripping depth (mm) | - |
