• Model NO.：XD103
• Travel Speed：0-10km,H
• Centrifugal Force：40KN
• Certification：ISO 9001:2000
• Condition：New
• Operating Weight：10000kg
• Load on Front Drum：5000kg
• Load on Rear Wheels：5000kg
• Minimum Turning Radius (in/out)：4070,5820mm
• Static Linear Load：280,280n,Cm
• Vibration Frequency(Low/High)：58,48Hz
• Engine Power：74.9kw
• Rated Engine Speed：2300r,Min
• Transport Package：Nude Package
• Specification：5700x2420x3060mm
• Origin：China
• HS Code：84294019
• Production Capacity：10000

ParameterUnitXD103Weight distributionWorking weightkg10000Front wheel distribution weight (kg)5000Rear wheel distribution weight (kg)5000Compaction performanceStatic linear loadN/cm280/280Nominal amplitudemm0.35/0.6Vibration frequencyHz58/48Exciting force (high frequency/low frequency)kN90/110Vibration wheel sizemm1150*1750ManeuverabilitySpeed rangekm/h0~6/0~12Theoretical gradeability%35Minimum turning radius (in/out)mm4070/5820Swing angle°±10Steering angle°±38EngineRated powerkW74.9Rated speedr/min2300
