• Model NO.：XS183
• Travel Speed：0~10km,H
• Condition：New
• Operating Weight：18000kg
• Load on Front Drum：11500kg
• Load on Rear Wheels：6500kg
• Drum Width：2130mm
• Static Linear Load：529n,Cm
• Vibration Frequency(Low/High)：28,33Hz
• Engine Model：Deutz Bf6m2012c
• Engine Power：136kw
• Rated Engine Speed：2200r,Min
• Transport Package：Nude Package
• Specification：4770*2250*3285mm
• Origin：China
• HS Code：84294019
• Production Capacity：10000

TypeUnitXS183Operating weightkg18000Load applied on front drumkg11500Load applied on rear wheelskg6500Compacting widthmm2130Static linear loadN/cm529Vibration frequency(Low/High)Hz28/33Nominal amplitude(High/Low)mm1.86/0.93Exiting force(High/Low)KN340/240Travel speedkm/h0~10Steering angle°±33Swing angle°±10Theoretical  gradeability%50Min. external turning radiusmm6500Engine model DEUTZ BF6M2012CEngine powerkw136Rated engine speedr/min2200Engine oil consumptiong/kW.h222Hydraulic oil tank capacityL240Fuel tank capacityL240
