• Model NO.：FR60E
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Operating Weight：5730kg
• Bucket Width：400mm
• Walking Speed：4.2,2.5 Km,H
• Operation Hydraulic Pressure：32 MPa
• Power：36.2,2100 Kw,Min-1
• Engine：Yanmar
• Max. Digging Height：5170 mm
• Max. Digging Depth：3925 mm
• Max. Digging Radius：6110 mm
• Transport Package：Nude
• Specification：6090*1950*2660
• Trademark：YANMA
• Origin：China
• HS Code：8429521200
• Production Capacity：100units Per Month

Operation Weight (Standard Configuration) (kg)5730Standard Bucket Capacity ( m3)0.18Rated Power/Rotate Speed (KW/rpm)36.2/2100Transport Dimensions(mm)6090*1950*2660Bucket Breakout Force (KN)42Stick Breakout Force (KN)31Maximum Traction (KN)50.5DeviceHigh-low Speed (Km/h)4.2/2.5Climbing Performance(°)35Total Length of the Crawler2550Tail Turning Radius (mm)1700Width of the Crawler400Ground Pressure (Kpa)32.33Turning MechanismTurning Speed (rpm)10.2EngineModelYANMAR 4TNV94LTypeFour Cylinders, Direct Injection, Naturally Aspirated, Water-coolingRated Torque/Rotate Speed (N.m/rpm)198/1400Cylinder Diameter*Stroke (mm)94*110Output Value (L)3.054Fuel Consumption (g/KW.h)247Fuel Tank Capacity (L)120Hydraulic SystemMain Pump Pressure (Mpa)24.5Main Pump Flow135*2Operating ScopeMaximum Digging Height (mm)5170Maximum Dumping Height (mm)3500Maximum Digging Depth (mm)3925Maximum Digging Radius (mm)6110
