• Model NO.：6116E
• Centrifugal Force：300,180 Kn
• Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Rated Power：103kw
• Theoretical Gradeability：30%
• Transport Package：Container,Roro,Bulk
• Specification：16000kg
• Trademark：LIUGONG
• Origin：China
• HS Code：8429401900
• Production Capacity：100units,Month

Product Parameters

Operating Mass

16000 kg

Mass On Vibrating Drum

8000 kg

Mass On Drive Axle

8000 kg

Front Drum Static Linear Load

368 N/cm

Model

SC4H140.2G2

Emission Regulation

Stage II

Rated Power

103 kW (140 hp) @ 2000 rpm

Vibration Frequency

30 Hz

Nominal Amplitude

2.0/1.2 mm

Centrifugal Force

300/180 kN

Drum Diameter

1555 mm

1st Maximum Speed, fwd

2.7 km/h

2nd Maximum Speed, fwd

5.2 km/h

3rd Maximum Speed, fwd

11 km/h

Theoretical Gradeability

30%

Min. GroundClearance

450 mm

Wheelbase

2950 mm

Min. Outside Turning Radius

6500 mm

Overall Length

6000 mm

Overall Width

2280 mm

Overall Height

3050 mm
