• Model NO.：LTS214H
• Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Rated Power：110kw
• Grade Ability：30%
• Transport Package：Container,Roro,Bulk
• Specification：14000kg
• Trademark：LUTONG
• Origin：China
• HS Code：8429401900
• Production Capacity：100units,Month

Power System: CUMMINS B-series turbocharged diesel engine, huge power man efficiency, compliance for the operating condition above 4000 meters altitude.

Hydraulic single drive,hydraulic vibration,hydraulic articulated steering,advanced technology;Blocking the oil supply to brake the vehicle,safe and reliable.

Streamline outline, circular windshield glass and curvy hood form a unique style.

The main hydraulic components made of imported brands.

Equipped with sheep foot (padfoot) or removal sheep foot (padfoot) as option

MODEL

LTS214H

LTS212H

LTS208H

Operating mass

Kg

14000

12000

8000

Static linear load

N/cm

326

286

230

Vibrating amplitude

Mm

1.7/0.8

1.6/0.8

0.4

Vibrating frequency

Hz

29/35

29/35

43

Centrifugal force

KN

290/180

260/160

70

Travel speed

Km/h

12

10.2

10

Grade ability

%

30

30

25

Turning radius

mm

7000

7000

6000

Overall dimension

mm

5900×2280×3050

5610×2280×3000

5030×1880×2570

Vibration round width

mm

2100

2100

1700

Wheelbase

mm

3185

3060

2684

Ground clearance

mm

400

360

280

Diesel power

kW

110

110

75

Diesel model

 CUM-MINS 6BT5.9

CUM-MINS 6BT5.9

CUM-MINS 4BT3.9
