• Model NO.：Clg6114e
• Travel Speed：30cm,s
• Centrifugal Force：30.5KN
• Certification：CE, ISO 9001:2000
• Condition：New
• Wheelbase：2950mm
• Operating Weight：14000kg
• Static Linear Load：315n,Cm
• Transport Package：Roro,Container
• Specification：6000x2280x3050mm
• Trademark：TOP BRAND
• Origin：China
• HS Code：84295100
• Production Capacity：100units,Month

Product Parameters

Mass

Operating Mass(kg)

14000

Mass On Vibrating Drum(kg)

7400

Mass On Drive Axle(kg)

6600

Front Drum Static Linear Load (N/cm)

340

Compaction

Vibration Frequency(Hz)

30/33

Nominal Amplitude(mm)

1.95/0.9

Centrifugal Force(kN)

300/180

Drum Diameter(mm)

1500

Drum Width(mm)

2130

Drum Thickness(mm)

30

Drive

1st Maximum Speed,fwd(km/h)

4.5

2nd Maximum Speed,fwd(km/h)

6.1

3rd Maximum Speed,fwd(km/h)

6.7

4th Maximum Speed,fwd(km/h)

12

Theoretical Gradeability(%)

50

Min. Ground Clearance(mm)

490

Wheelbase(mm)

3000

Steering Angle(°)

±35

Swing angle(°)

±10

Min. Outside Turning Radius(mm)

6500

Tyre Type

23.1-26-12PR

Tyre Pressure(kPa)

200-220

Overall Length(mm)

6000
