• Model NO.：DH17
• Condition：New
• Color：Orange
• Operating Weight：17500kg
• Emission：China II
• Maximum Torque：900,1400-1600 N.M,R,Min
• Length：5250mm
• Width：3420mm
• Height：3080mm
• Transport Package：Nude Packing
• Specification：140kW
• Trademark：SHANTUI
• Origin：China
• HS Code：8429119000
• Production Capacity：100units,Mouth

Overview Product Description

Product Parameters



PRODUCTDH17 B2 XL PERFORMANCE PARAMETERSOperatiing Weight (kg)17500 (Ripper not included)Rated horsepower (kw/hp)140/188@1900Minimum turning radius (mm)2390/3600Ground pressure (kpa)64ENGINEModelWeichai WD10G190E214EmissionChina IITypeIn-line, direct injection, water cooled, 4-cycles, turbochargedNo. of cylinders×Bore×stroke (mm×mm)6×126mm×130mmPiston displacement (L)9.726Horsepower/rpm (kw/rpm)140/1900Maximum torque (N.m/r/min)900/1400-1600DIMENSIONSLength (mm)5250Width (mm)3420Height (mm)3080TRAVELING PERFORMANCEForward/Reverse (km/h)0~10Gradeability (deg)30Clearance (mm)370TRANSMISSIONTraveling pump (Linde)Variable displacement piston pump, maximum flow 135ml/rTraveling motor (Linde)Variable displacement piston motor, maximum flow 210ml/rPump for oil refillGear pump, flow 63ml/rCouplingElastic couplingFinal driver1 stage spur gear and 1stage planetary reductionBrakeWet, closed brakeUNDERCARRIAGESuspensionOscillating equalizer bar and pivot shaftTrack gauge (mm)1880Shoe width (mm)510/560/610Track length on ground (mm)2675Number of shoes (each side)39Pitch (mm)203Carrier rollers (each side)2Track rollers (each side)7WORKING HYDRAULIC SYSTEMWorking hydraulic pumpGear pump, flow 80ml/rPPC pumpGear pump, flow 10ml/rValveMulti-way valveBore of blade lift cylinder (mm)φ95Bore of blade tilt cylinder (mm)φ140TANK CAPACITYFuel tank capacity (L)305Working hydraulic tank capacity (L)85Transmission hydraulic tank capacity (L)65Working equipmnetBlade width (mm)3400 (Semi-U blade) / 3388 (Straight-tilt blade)Blade height (mm)1200 (Semi-U blade) / 1149 (Straight-tilt blade)Blade capacity (m³)4.7 (Semi-U blade) / 4.5 (Straight-tilt blade) Detailed Photos
