• Model NO.：SD22
• Condition：New
• Color：Orange
• Operating Weight：23450kg
• Emission：China I
• Maximum Torque：1030,1250 N.M,R,Min
• Length：5495mm
• Width：3725mm
• Height：3402mm
• Transport Package：Nude Packing
• Specification：175kW
• Trademark：SHANTUI
• Origin：China
• HS Code：8429119000
• Production Capacity：100units,Mouth

Overview Product Description

Product Parameters



PRODUCTSD22 PERFORMANCE PARAMETERSOperatiing Weight (kg)23450Rated horsepower (kw/hp)175/1800Minimum turning radius (mm)3300Ground pressure (kpa)66ENGINEModelChongqing cunmins NT855-C280S10EmissionChina   ITypeIn-line,direct injection,water cooled,4-cycles,turbochargedNo.of cylinders×Bore×stroke (mm×mm)6×140×152Piston displacement (L)14Horsepower/rpm (kw/rpm)175/1800Maximum torque (N.m/r/min)1030/1250DIMENSIONSLength(mm)5495Width(mm)3725Height(mm)3402TRAVELING PERFORMANCEForward/Reverse (km/h)F1:0-3.6   F2:0-6.5 F3:0-11.2 R1:0-4.3  R2:0-7.7   R3:0-13.2Gradeability(deg)30Clearance(mm)405TRANSMISSIONTorque convertor3-element, single stage, 1-phaseGear boxPlanetary gear and powershift transmission, hydraulically actuated, forced lubricationMain driveSpiral bevel gear, single-stage speed reduction, splash lubricationSteering clutchWet multiple disc,coned disc spring loaded, hydraulically actuated, hand   operated, interconnected with steering brakeBrakeWet, contracting band, foot operated with hydraulic boosterFinal driverspur gear, double reduction, splash lubricationUNDERCARRIAGESuspensionSwing type of sprayed beam, suspended structure of equalizer barTrack gauge (mm)2000Shoe width (mm)560Track length on ground (mm)2730Number of shoes (each side)38Pitch (mm)216Carrier rollers (each side)2Track rollers (each side)6WORKING HYDRAULIC SYSTEMPressure (MPa)14Working pumpGear pumpValveMulti-way valveBore of blade lift cylinder (mm)φ120 Bore of blade tilt cylinder (mm)φ200 TANK CAPACITYFuel  tank capacity (L)450Working hydraulic tank capacity (L)110WORKING EQUIPMENTBlade width (mm)3725Blade height (mm)1315Blade capacity (m³)6.4Max. Drop below ground of blade1210Lift height of blade540Type of ripperSingle shank/3 shanksMaximum digging depth of ripper (mm)Single 695 Three 666Maximum lifting height of ripper (mm)Single 515 Three 555



Detailed Photos
