• Model NO.：SD32
• Condition：New
• Color：Orange
• Operating Weight：33600kg
• Maximum Torque：1440,1400 N.M,R,Min
• Length：8650mm
• Width：4130mm
• Height：3760mm
• Transport Package：Nude Packing
• Specification：257kW
• Trademark：SHANTUI
• Origin：China
• HS Code：8429111000
• Production Capacity：50units,Mouth

Overview Product Description

Product Parameters



PRODUCTSD32 PERFORMANCE PARAMETERSOperatiing Weight (kg)33600Rated horsepower (kw/hp)257/345Minimum turning radius (mm)3800Ground pressure (kpa)81.7ENGINEModelNTA855-C360S10EmissionChina ITypeIn-line, direct injection, water cooled, 4-cycles, turbochargedNo.of cylinders×Bore×stroke (mm×mm)6×140×152Piston displacement (L)14Horsepower/rpm (kw/rpm)257/2000Maximum torque (N.m/r/min)1440/1400DIMENSIONSLength (mm)8650Width (mm)4130Height (mm)3760TRAVELING PERFORMANCEForward/Reverse (km/h)F1:0-3.6
F2: 0-6.6
F3: 0-11.5
R1:0-4.4
R2: 0-7.8
R3: 0-13.5Gradeability (deg)30Clearance (mm)500TRANSMISSIONTorque convertor3-element, single stage, 1-phaseGear boxPlanetary gear and powershift transmission, hydraulically actuated,mforced lubricationMain driveSpiral bevel gear, single-stage speed reduction, splash lubricationSteering clutchWet multiple disc,coned disc spring loaded, hydraulically actuated, hand   operated,interconnected with steering brakeBrakeWet, contracting band, foot operated with hydraulic boosterFinal driverspur gear, double reduction, splash lubricationUNDERCARRIAGESuspensionSwing type of sprayed beam, suspended structure of equalizer barTrack gauge (mm)2140Shoe width (mm)560Track length on ground (mm)3150Number of shoes (each side)41Pitch (mm)228.6Carrier rollers (each side)2Track rollers (each side)7WORKING HYDRAULIC SYSTEMPressure (MPa)14Working pumpGear pumpValveMulti-way valveBore of blade lift cylinder (mm)140Bore of blade tilt cylinder (mm)225TANK CAPACITYFuel tank capacity (L)640Working hydraulic tank capacity (L)97WORKING EQUIPMENTBlade width (mm)4130Blade height (mm)1710Blade capacity (m³)10.5 (Semi-U)Max. drop below ground of blade1560Lift height of blade560Type of ripperSingle shank/Three shanksMaximum digging depth of ripper (mm)1250/842Maximum lifting height of ripper (mm)1590 Detailed Photos
