• Model NO.：XD143S
• Travel Speed：0-10km,H
• Centrifugal Force：40KN
• Certification：ISO 9001:2000
• Condition：New
• Operating Weight：14000kg
• Load on Front Drum：7000kg
• Load on Rear Wheels：7000kg
• Minimum Turning Radius mm (in/out)：4470,6600
• Static Linear Load：330,330n,Cm
• Vibration Frequency(Low/High)：67,50Hz
• Engine Power：111kw
• Rated Engine Speed：2100r,Min
• Theoretical Gradeability：35%
• Transport Package：Nude Package
• Specification：6010*2300*3200mm
• Origin：China
• HS Code：84294019
• Production Capacity：10000

ParameterUnitXD143SWeight distributionWorking weightkg14000Front wheel distribution weight 7000Rear wheel distribution weight 7000Compaction performanceStatic linear load N/cm330/330Nominal amplitude mm0.3/0.8Vibration frequency Hz67/50Exciting force (high frequency/low frequency) kN110/170Vibration wheel size mm1300×2130ManeuverabilitySpeed range km/h0~6,0~8,0~12Theoretical gradeability %35Minimum turning radius mm (in/out) 4470/6600Swing angle°±8°Steering angle°±35°EngineType Inline four-cylinder pressurized water-cooledRated powerkW111Rated speedr/min2100
