• Model NO.：SD16
• Condition：New
• Color：Yellow
• Dimension：5410x3388x3032mm
• Engine：Shangchai C6121zg70b,Steyr Wd10g175e15
• Ground Clearance：400mm(Straight-Tilt)
• Operating Weight：17t
• Transport Package：Suitable Package for Shipment
• Specification：160hp
• Trademark：Shantui
• Origin：Shandong, China
• Production Capacity：300 Sets,Month

Basic Info.

Model NO. SD16 Condition New Color Yellow Dimension 5410x3388x3032mm Engine Shangchai C6121zg70b/Steyr Wd10g175e15 Ground Clearance 400mm(Straight-Tilt) Operating Weight 17t Transport Package Suitable Package for Shipment Specification 160hp Trademark Shantui Origin Shandong, China Production Capacity 300 Sets/Month

Product Description

Chinese Shantui 160HP Crawler Track Bulldozer (SD16)

Engine
Model...Shangchai C621/STEYR WD615TI-3A
Water cooled, in-ine, 4-stroke injection direct
Rated horsepower...120Kw
Cylinder number-bore X stroke...6-126mm X 130mm
Piston displacement...9.726L
Min. Fuel consumption...214G/Kw. H
Max. Torque...764N. M

Power Transmitting System
Torque Converter...3-element, 1 stage, 1phase
Transmission...Planetary gear type, power-shift, forced lubrication
Main Drive...Spiral bevel gear, single-stage speed reduction dplsdh luntivsyion.
Steering Clutch...Wet, multi-disc, spring loaded, hand hydraulically separated, inter-linking with steering brake.
Steering Brake...Wet, floating band structure, foot brake with hydraulic booster
Final drive...Tow-stage speed reduction of spur gear, splash lubrication

Specification Blade Type	Straight-tilt	Angle	U-type
Min. ground clearance(mm)	400	400	400
Ground pressure(MPa)	0.067	0.067	0.067
Min. turning radius(m)	4.7	4.5	4.9
Gradeability(° )	30	30	30
Track gauge(mm)	1880	1880	1880
Dozing capacity(m3)	4.5	4.4	5.0
Efficiency(Theoretical value in 40m)(m3 /h)	225	225	250
Blade width(mm)	3388	3970	3556
Blade height(mm)	1149	1090	1120
Max. drop below ground (mm)	540	540	530
Max. tilt adjustment(mm)	400	-	400
