1.5tons Site Dumper with Mechanic Tipping SD15 11d
Wuhan Kudat Industry & Trade Co., Ltd.- Drive Model：2WD
- Dry Mass(Kg)：1500
- Engine Model：S1100bnm
- Engine Type：Horizontal Single-Cylinder Four-Stroke, Radiator W
- Steering Gear：Worm-and-Double-Roller Type
- Gear Box with：Selective-Gear Transmission, with Three Forward Sp
Base Info
- Model NO.：SD15-11D
- Skip Capacity (M3)：0.75
- Tipping System：Hydraulic Tipping Hopper
- Max, Grade Ability (%)：21
- Electric Starting：Yes
- Transport Package：Nude
- Specification：CE
- Trademark：KUDAT
- Origin：China
- HS Code：8430
- Production Capacity：500units,Month
Description
ModelSD15-11D Drive Model 2WD Length(mm) 2917 Width(mm) 1600 Height(mm) 2100 Wheel Base Wheel Base(mm) 1500 Wheel Tread Front Wheel(mm) 1320 Rear Wheel(mm) 1290 Min Ground Clearance(mm) ≥205 Dry Mass(Kg) 1500 Engine Model S1100BNM Type Horizontal single-cylinder four-stroke, radiator water-cooled 12 Hours Rated Power(rpm) 11/2200 Tyre Front Wheel 7.50-16 Rear Wheel 5.00-15 Clutch Constant-contact, single-disc, dry clutch Brake Drum type with mechanical control Steering Gear Worm-and-double-roller type Gear Box With Selective-gear transmission, with three forward speeds and one reverse speed Ground Speed (Km/H) 1st Gear 5.5 2nd Gear 11 3rd Gear 22 4th Gear - Reverse 4.8 Skip Capacity (m3) 0.75 Minimum Turning Radius (m) 4 Tipping System Hydraulic Tipping hopper Max, Grade Ability (%) 21 Electric Starting Yes
Description:
1.Wheel type mini dumper
2.With power steering and powerful 15HP engine, it's easier to move at slope
or rugged area.
3. with transmission for car, it's possible to change speed during travel.
4. Efficiency of transportation by transportation, loading, unloading and dumping ability.
5.4*2 driving articular frame with hydraulic steering
6.China made F3L912 air cooled diesel engine with Deutz technology/
NB485 water engineering diesel engine
Applications:
Dumpers are widely used in many different of site works, such as the construction
industry,the factory floor, battlefield ,protecting road section, the municipal engineering,
underground mines and so on.
Competitive Advantage:
1.As a low-volume, short-distance transport of bulk materials for small site dumpers,
because of its easy operation, small turning radius can be used in a narrow environment,
etc,.
2.Full Cover of Diesel Engine
3.Strong and Heavy Duty Frame and Chassis
4.Bucket can be full automatically tipped by hydraulic cylinder
5.Direction change of dumper can be easily controlled by hydraulic steering wheel
Description:
1.Wheel type mini dumper
2.With power steering and powerful 15HP engine, it's easier to move at slope
or rugged area.
3. with transmission for car, it's possible to change speed during travel.
4. Efficiency of transportation by transportation, loading, unloading and dumping ability.
5.4*2 driving articular frame with hydraulic steering
6.China made F3L912 air cooled diesel engine with Deutz technology/
NB485 water engineering diesel engine
Applications:
Dumpers are widely used in many different of site works, such as the construction
industry,the factory floor, battlefield ,protecting road section, the municipal engineering,
underground mines and so on.
Competitive Advantage:
1.As a low-volume, short-distance transport of bulk materials for small site dumpers,
because of its easy operation, small turning radius can be used in a narrow environment,
etc,.
2.Full Cover of Diesel Engine
3.Strong and Heavy Duty Frame and Chassis
4.Bucket can be full automatically tipped by hydraulic cylinder
5.Direction change of dumper can be easily controlled by hydraulic steering wheel
