• Model NO.：SD7
• Condition：New
• Color：Blue
• Weight：23800kg
• Power：220HP
• Ground Pressure(Without Ripper) ：71.9 Kpa
• Ground Clearance：404 mm
• Ground Contact Length ：2890 mm
• Track Center Distance：1980 mm
• Overall Dimensions：7604*3823*3402
• Dozing Operation Rate：350m 3 ,H
• Flywheel Power：16kw
• Starting Mode：24V Electric Starting
• Transport Package：Bulk
• Specification：SGS
• Trademark：KUDAT
• Origin：China
• Production Capacity：500PCS,Year

Operating weight(not including ripper) 23800 KGSRipper weight3900 KGSEngine flywheel power 162 KWGround pressure(without ripper) 71.9 kPaGround clearance404 mmGround contact length 2890 mmTrack center distance1980 mmOverall dimensions(L × W × H)(with single shank ripper)
7604 × 3823 × 3402(with straight tilting blade)Grade-abilityLatitude30  °     Transverse 25 °Theory travel speed      (km/h1st gear forward           0-3.91st   gear backward         0-4.82nd gear forward         0-6.5   2nd gear backward         0-8.23rd gear forward         0-10.93rd gear backward 0-13.2Dozing operation rate(moving distance 40m )350m 3 /hDiesel  engine  specificationsModel NT855-C280 (Cummins)Type water cooled, single line, vertical, four strokes, turbocharged, 6-cylindersFlywheel power(speed at 2100 rpm)16 kW
 Starting mode24V electric starting
