• Model NO.：(LG6220d)
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Product Name：22 Ton Lonking Crawler Excavator (LG6220d)
• Rated Power：112kw (150HP) ,1950 Rpm
• Max. Torque：614 N.M,1500 Rpm
• Transport Package：Nude Package
• Specification：cummins engine
• Trademark：lonking
• Origin：China
• HS Code：8429521200
• Production Capacity：1000pieces,Year

SpecificationsLG6220DEngineModelCummins6BTAA5.9-CRated power112kW (150hp) /1950 rpmMax. torque614 N.m/1500 rpmBore× Stroke102mm×120mmDisplacement 5.9 CommentMaintain the rated power at 2300m elevation.Operating weightSummaryOperating weight:21800kg The operating weight includes the weight of 5675 mm standard boom,2920 mm standard arm,
1.0m3 standard bucket,600 mm track shoes,lubricating oil, coolant,the full diesel oil tank and the rest standard configuration units.Ground pressure51 kPaFluid capacityFuel tank380 LCooling system23 LEngine oil18 LSwing drive unit3.8 LTraveling gear 2×3.3 LHydraulic oil tank280 LSwing mechanismHigh torque plunger motor and 2-stage planetary reducer drive. Brake inside loading motor is applied by
spring and released by hydraulic unit. The automatic braking is available when the swing control lever is in neutral position.Swing speed :11.6 rpmTravel driveSummaryThe integrated 2-speed plunger hydraulic motor and reducer drive, motor and hydraulic pipeline are arranged inside the track frame
to prevent the damage caused by the rugged road surface, The motor inside is provided with the service brake and shock absorption
valve to ensure the smooth running and stop and the reliable braking. Taveling speed3.0 -5.2 km/hGradeability35°(70%)MaximumTraction222 kNTraveling mechanismStandard track shoe width600 mmNo. of track shoe47 (each side)No. of carrierrollers2 (each side)No. of track rollers8 (each side)Hydraulic systemMain pumpDuplex axial variable plunger pumpPilot pumpgear pump (integrated in main pump)Max. flow of system2×208 L/minMax. pressure of equipment34.3 MPaMax. pilot pressure3.9 MPaOperating equipmentEach machine action is under the pilot control. The right lever controls the motion of boom and bucket while
the left lever controls the arm motion and upper structure swing. The foot pilot valve is provided with the lever
joystick to control the machine traveling or turning by the foot or lever. The traveling gear shift adopts the solenoid switch control. Electrical systemSystem voltage:24 V Battery:12 V,120 A×2
