• Model NO.：SG16-3
• Engine：Cummins 6btaa5.9-C160
• Rated Power：118kw,2200 Rpm
• Piston Displacement：5.9L
• Color：Yellow
• Number of Cylinders：6(102X120mm)
• Maximum Torque/Speed：670n M,1500 Rpm
• Minimum Fuel Consumption：205 G,Kw H
• Tyre：17.5-25pr12
• Transport Package：Nude Packing
• Trademark：SHANTUI
• Origin：China
• Production Capacity：200units,Month

EngineEngine modelCummins 6BTAA5.9-C160Rated power/speed118   kW/2200 rpmEngine typeIn-line,   water cooled,4 -cycle, direct injection, turbochargedNumber of cylinders6(102X120mm)Piston displacement5.9LMaximum torque/speed670   N·m/1500 rpmMinimum fuel consumption 205 g/kW·htravel speedTransmission   and torque converter: Electronic controlled transmission with 6 forward gears   and 3 reverse gears.Gear1st2nd3rd4th5th6thForward0~5.4   km/h0~8.4   km/h0~13.4   km/h0~20.3   km/h0~29.8   km/h0~39.6   km/hReverse0~5.4   km/h0~13.4   km/h0~29.8   km/h   TRAVELTire   Type17.5-25PR12Steering systemMax.   steering angle of front wheel ±45°Max. tilting angle of front wheel±17°Max. oscillating angle of front axle±15°Steering angle of frame±25°Max. oscillating angle of rear axle±15°Min. turning radius7800 mmOperation weightOperating   weight (standard configuration)15400 kgFront axle load4600 kgRear axle load10800 kgBladeBlade   length 3660/3965   mmBlade heightB 635 mmBlade rotational angle360°Cutting angle adjustment range44~91°Maximum cutting depth 500 mmCutting force per dozing 23.5 kN/mMaximum lift above ground 440 mmMaximum blade lateral extension (left/right) 1900/1950   mm
