• Model NO.：SE210-9
• Size：Medium-Sized
• Certification：ISO9001: 2000
• Condition：New
• Quantity of Cylinders：6
• Color：Yellow
• Engine：Imported Cummins
• Bore X Stroke：107 X 124 mm
• Displacement：6.7L
• Power Output：124 Kw,2050 Rpm
• Operating Weight：20800kg
• Standard Bucket：0.9m3
• Bucket Width：1267mm
• Transport Package：Nude Packing
• Trademark：SHANTUI
• Origin：China
• Production Capacity：200units,Month

ENGINEModelCummins B5.9Type

High pressure and common rail,

water cooling, in-line ,6 cylinders, turbocharging

Quantity of cylinders6Bore x stroke107 x 124 mmDisplacement6.7 LPower output124 kW/2050 rpmMaximum torque658N.m/800-1800rpmHYDRAULIC SYSTEMPumpImportedTypeVariable piston pumpMaximum discharge flow2x213 L/minControl circuit3.9 MPaTravel circuit34.3 MPaSwing circuit25.5 MPaTRAVEL SYSTEMTravel motorVariable axial piston motorTravel brakesLubricated double-discParking brakePressure releaseTravel shoes2 x 46Travel speed3.15/5.15 km/hDrawbar pulling force214 kNGradeability70%Minimum ground clearance470 mmOIL CAPACITYFuel tank330 LCooling system28 LEngine oil22 LHydraulic oil tank270 LSystem capacity400 LSWING SYSTEMBrakePressure Release Mechanical BrakingSwing speed11 rpmTail swing radius2925 mmArm digging force99/107 KNBucket digging force135/146 KNBUCKETBucket capacityBackhoe bucket 0.9 m3 (SAE)Number of bucket teeth5Bucket width1267 mmArm length2.925 m

Maximum digging reach/Maximum digging

reach at ground level

9.86 m/9.675 mMaximum digging depth/height6.49 m/10.095 mMaximum dumping height7.19 mMinimum swing radius2.97 m
