Shantui 13.5ton 0.55m3 Crawler Excavator Se135 with Cummins Engine

Evangel Industrial (Shanghai) Co., Ltd.
  • Type：Crawler Excavator
  • Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
  • Bucket：Grab Shovel
  • Transmission：Hydraulic Transmission
  • Drive Type：Electric Drive
  • Bucket Capacity：0.5~1.0m³

Base Info

  • Model NO.：SE135
  • Size：Small-Scale
  • Certification：ISO9001: 2000
  • Condition：New
  • Engine：Cummins Qsf3.8t
  • Quantity of Cylinders：4
  • Bore X Stroke：102 X 115 mm
  • Displacement：3.76L
  • Power Output：86 Kw,2200 Rpm
  • Minimum Ground Clearance：425mm
  • Fuel Tank：220L
  • Hydraulic Oil Tank：177L
  • Transport Package：Nude Packing
  • Trademark：SHANTUI
  • Origin：China
  • Production Capacity：200units,Month

Description

ENGINEModelCummins QSF3.8TType4-cylinder in line, water cooling,
turbo chargingQuantity of cylinders4Bore x stroke102 x 115 mmDisplacement3.76 LPower output86 kW/2200 rpmHYDRAULIC SYSTEMPumpImportedTypeVariable piston pumpMaximum discharge flow2 x 130 L/minControl circuit3.9 MPaTravel circuit35 MPaSwing circuit27 MPaTRAVEL SYSTEMTravel motorVariable axial piston motorTravel brakesLubricated double-discParking brakePressure releaseTravel shoes2 x 44Travel speed3.25/5.2 km/hDrawbar pulling force118 kNGradeability70% (35°)Minimum Ground clearance425 mmOIL CAPACITYFuel tank220 LCooling system20 LEngine oil12 LHydraulic oil tank177 LSystem capacity205 LSWING SYSTEMBrakePressure Release Mechanical BrakingSwing speed11.3 rpmTail swing radius2380 mmArm digging force70 KNBucket digging force97 KNBUCKETBucket capacityBackhoe bucket 0.55 m3 (SAE)Number of bucket teeth4Bucket width990 mmArm length2.5 mMaximum digging reach/Maximum digging
reach at ground level8.3 m/8.175 mMaximum digging depth/height5.49 m/8.495 mMaximum dumping height6.065 mMinimum swing radius2.445 mShantui 13.5ton 0.55m3 Crawler Excavator Se135 with Cummins Engine
