Shantui 0.9m3 21t Crawler Excavator Se210W with Weichai Euro III Engine

Evangel Industrial (Shanghai) Co., Ltd.
  • After-sales Service：Online Video Support
  • Warranty：One Year
  • Type：Crawler Excavator
  • Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
  • Bucket：Backhoe
  • Transmission：Hydraulic Transmission

Base Info

  • Model NO.：SE210W
  • Drive Type：Electric Drive
  • Bucket Capacity：0.5~1.0m³
  • Size：Medium-Sized
  • Certification：ISO9001: 2000
  • Condition：New
  • Engine：Weichai Wp7
  • Rated Power：116kw,2000rpm
  • Displacement：7.14L
  • Max. Digging Height：10029mm
  • Max. Dumping Height：7320mm
  • Max. Digging Depth：6541mm
  • Max. Digging Reach：9860mm
  • Min. Swing Radius：3041mm
  • Std. Track Shoe Width：600mm
  • Transport Package：Nude Packing
  • Trademark：SHANTUI
  • Origin：China
  • Production Capacity：200units,Month

Description

SE210WEngine Engine modelWeichai WP7Rated power116kw/2000rpmMax.torque630N·M/1400~1500rpmDisplacement7.14 LEmission   standardTier 3Operation   Range Operating   weight20500 kgMax. digging   height10029 mmMax. dumping   height7320 mmMax. digging   depth6541 mmMax. vertical   digging depth5735 mmMax. digging   reach9860 mmMin. swing   radius3041 mmDimensions Overall   length9543 mmOverall width2800 mmOverall   height2977 mmTail swing   radius2905 mmMin. ground   clearance470 mmCounterweight   ground clearance1120 mmUndercarriage/Working   Device Std. track   shoe width600 mmBucket   capacity0.9 m³Carrier   roller(per side)2Track   roller(per side)7Track gauge2200 mmBoom length5700 mmArm length2925 mmPerformance Travel speed3.3/5.4 km/hGradeability35°Ground   pressure45 kPaTractive   force201 kNBucket   digging force124 kNArm digging   force99.5 kNService   Refill Capacities Fuel tank360 LEngine   coolant25 LEngine oil24 LHydraulic   tank250/420 LHydraulic   System TypeNegative flow
Hydraulic system with Variable Displacement Piston PumpPump flow2X218L/minSwing System Swing speed0-11.5r/minThe parameters are   for reference only, please contact your sales representative for details.Shantui 0.9m3 21t Crawler Excavator Se210W with Weichai Euro III Engine
