Shantui Small Tracked Type Excavator Se75W with Weichai Engine

Evangel Industrial (Shanghai) Co., Ltd.
  • Type：Crawler Excavator
  • Usage：Special Excavator, Marine Excavator, Mining Excavator, GM Excavator
  • Bucket：Grab Shovel
  • Transmission：Hydraulic Transmission
  • Drive Type：Electric Drive
  • Bucket Capacity：0.1~0.5m³

Base Info

  • Model NO.：SE75W
  • Size：Small-Scale
  • Certification：ISO9001: 2000
  • Condition：New
  • Engine：Weichai Wp3
  • Quantity of Cylinders：4
  • Bore X Stroke：94 X 107 mm
  • Displacement：2.97L
  • Power Output：48 Kw,2200 Rpm
  • Maximum Torque：260 Nm,1400-1600 Rpm
  • Bucket Width：860mm
  • Arm Length：1.65m
  • Transport Package：Nude Packing
  • Trademark：SHANTUI
  • Origin：China
  • Production Capacity：200units,Month

Description

ENGINEModelWeichai WP3Type4-cylinder in line, water-cooling, turbo charging, High pressure
and common railQuantity of cylinders4Bore x stroke94 x 107 mmDisplacement2.97 LPower output48 kW/2200 rpmMaximum torque260 NM/1400-1600 rpmHYDRAULIC SYSTEMPumpImportedTypeVariable piston pumpMaximum discharge flow160 L/minControl circuit3.5 MPaTravel circuit28 MPaSwing circuit23.5 MPaTRAVEL SYSTEMTravel motorVariable axial piston motorTravel brakesLubricated double-discParking brakePressure releaseTravel shoes2 x 39Travel speed2.9/4.8 km/hDrawbar pulling force63 kNGradeability70%Minimum ground clearance385 mmOIL CAPACITYFuel tank120 LCooling system11 LEngine oil11 LHydraulic oil tank140 LSystem capacity160 LSWING SYSTEMBrakePressure Release Mechanical BrakingSwing speed11 rpmTail swing radius1880 mmArm digging force44 KNBucket digging force66 KNBUCKETBucket capacityBackhoe bucket 0.32 m3 (SAE)Number of bucket teeth5Bucket width860 mmArm length1.65 mMaximum digging reach/Maximum
digging reach at ground level6.36 m/6.205 mMaximum digging depth/height4.12 m/6.945 mMaximum dumping height4.895 mMinimum swing radius2.04 mShantui Small Tracked Type Excavator Se75W with Weichai Engine
