500mm Milling Width Small Asphalt Cold Milling Machine Xm503
Evangel Industrial (Shanghai) Co., Ltd.- After-sales Service：Online Video Support
- Warranty：One Year
- Type：Milling Machine
- Object：Asphalt Concrete
- Moving Type：Mobile
- Automatic Grade：Automatic
Base Info
- Model NO.：XM503
- Certification：ISO9001: 2000
- Condition：New
- Milling Width：500mm
- Maximum Milling Depth：180mm
- Cutter Tip Pitch：15mm
- Amount of Tools：54pieces
- Diameter of Rotor：660
- Engine：Sc4h-C140
- Rated Power：92kw
- Transport Package：Nude Packing
- Trademark：EVANGEL
- Origin：China
- Production Capacity：200units Per Month
Description
Basic Info.
Model NO. XM503 Certification ISO9001: 2000 Condition New Milling Width 500mm Maximum Milling Depth 180mm Cutter Tip Pitch 15mm Amount of Tools 54pieces Diameter of Rotor 660 Engine Sc4h-C140 Rated Power 92kw Transport Package Nude Packing Trademark EVANGEL Origin China Production Capacity 200units Per MonthProduct Description
500mm milling width small asphalt concrete cold milling machine XM503| Item | Unit | XM503 |
| Milling width | mm | 500 |
| Maximum milling depth | mm | 180 |
| Cutter tip pitch | mm | 15 |
| Amount of tools(piece) | (piece) | 54 |
| Diameter of rotor | 660 | |
| Engine model | SC4H-C140 | |
| Engine manufacturer | Shangchai | |
| Rated speed | rpm | 2200 |
| Rated power | Kw | 92 |
| Emission standard | China-III | |
| Fuel tank | L | 140 |
| Water tank | L | 300 |
| Working speed | m/min | 0-40 |
| Traveling speed | Km/h | 0-6 |
| Theoretical gradeability | % | 50 |
| Maximum unloading height | mm | 1200 |
| Theoretical unloading capacity | m3/h | 42 |
| Gross machine weight | Kg | ≤7800/7300 |
| Minimum milling radius | mm | 350 |
| Ground clearance | mm | 180 |
