• Model NO.：CLG6114
• Engine Type：Diesel Engine
• Travel Speed：35cm,s
• Certification：EPA, CS, CE, RoHS, ISO 9001:2000, ISO 9001:2008
• Condition：New
• Color：Yellow
• Transport Package：Nude
• Specification：ISO
• Trademark：LIUGONG
• Origin：Guangxi, China
• Production Capacity：200000sets,Month

PerformanceStatic Linear Front Drum Load328 kg-mmWorking Width2,130 mmOverall dimension (L×W×H)6145*2230*3040 mmNumber of Vibrating Drum1Nominal Amplitude Range1.75 / 0.85 mmVibration Frequency Range30 HzCentrifugal Force Range270 / 135 kNNumber of Amplitude Settings1Operating WeightsOperating Weight with Ballast14,000 kgWeight on Front Drum7,150 kgWeight on Tires6,850 kgElectrical SyetemSystem Voltage24 VDrive TrainTheoretical Gradeability, without / with Vibration30%Transmission Typesynchronous shiftMaximum Speed, fwd11 km/hInside Turning Radius< 4,370 mmOutside Turning Radius< 6,500 mmHydraulic SystemMain Pump Type pistongear pumpMain Relief Pressure18 MPaTiresTire Size20.5 - 25 - 16 PRService CapacitiesFuel Tank285 LEngine Oil14 LCooling System 28 L32 LTransmission and Torque Converter14.5 LAxlesSteering SystemhydraulicSteering MethodarticulationSteering Angle ±35°±35°Steering Relief Pressure16 MPa
