• Model NO.：XE80
• Size：Small-Scale
• Certification：CE, ISO9001: 2000
• Condition：New
• Model：Xe80
• Standard Bucket Width：722 mm
• Operation Weight：7425 mm
• Min. Clearance：392 mm
• Total Displacement：3.3 L
• Rated Output Power：60 Kw
• Max. Digging Height：7167 mm
• Max. Dumping Height：5100 mm
• Max. Digging Depth：4140 mm
• Max. Digging Radius：6375 mm
• Transport Package：Nude Package
• Specification：ISO, CE, GOST
• Trademark：ORIEMAC
• Origin：China(Mainland), Jiangsu
• Production Capacity：1500 Units, Year

ModelXE80Bucket capacitym30.34Standard bucket widthmm722Operation weightkg7,425Dimension
(in transportation)Overall lengthmm6,155Overall widthmm2,220Overall heightmm2,618Min. clearancemm392EngineModelCumminisB3.3Total displacementL3.3Rated output powerKW/rpm60/2200Digging performanceMax. digging heightmm7,167Max. dumping heightmm5,100Max. digging depthmm4,140Max. vertical digging depthmm3,218Max. digging radiusmm6,375Boom deflection angle  ° Min. slew radiusmm1,815Min. rear slew radiusmm1,770Bucket digging forcekn53.6Track typeSteelTrack widthmm450Travel SystemTrack lengthmm2,752Wheel basemm2,119Track gaugemm1,700Travel speed (Gear I/II)km/h4.2/2.7Gradeability%70Slew speedrpm12Bulldozing plateBulldozing plate widthmm Bulldozing plate heightmm Lifting distancemm Hydraulic pump typeVariable pump*1
 +gear pump*1Slew motor typePiston hydraulic motorTravel motor typePiston hydraulic motorFuel tank capacityL135Hydraulic oil tank capacityL130
