Lds2000g Gasoline Power Auto Mortar Render Spray Machine

Zhengzhou Lead Equipment Co., Ltd.
  • Type：Shotcrete
  • Shotcrete Type：Wet
  • Machining Process：Hydraulic
  • Structure：Spiral Type
  • Productivity：6-8m3,H
  • Feeding Height：1370mm

Base Info

  • Model NO.：LDS2000G
  • Vibrating Amplitude：0.8mm
  • Certification：ISO9001: 2000, CE, SGS
  • Condition：New
  • Color：White
  • Hopper Volume：240L
  • Hopper Rated Rev.：76r,Min
  • Oil Tank：130L
  • Hydraulic：Yes
  • Usage：Dome Building, Swimming Pool etc.
  • Application：Pumping,Grouting,Spraying,Plaster
  • Power Option：Diesel, Electric, Gasoline
  • Working Pressure：1.5 MPa (Chinese Hose),3.5 MPa (Trelleborg Hose)
  • Max. Aggregate：10mm
  • The Squeeze Hose：ID 50mm
  • Transport Package：Seaworthy Packing: Plywood Box Shotcrete Machine
  • Specification：CE, ISO
  • Trademark：Leadcrete
  • Origin：Henan, China
  • Production Capacity：6-8m3,H

Description


Item
Description
Working Pressure
1.5 Mpa (Chinese Hose)/3.5 Mpa (Trelleborg Hose)
Output
6-8m3/h
Max. Aggregate
10mm
The Squeeze Hose
ID 50mm
Conveying Hose
ID 50mm
Squeeze pump
GH50-680
Power
Honda GX390 Gasoline Engine (low pressure)
Honda GX630 Gasoline engine(high pressure)
Hopper volume:
240 Liter
Hopper rated rev.
76r/min
Oil tank
130 Liter
Requested air compressor
6m3/min, 0.6Mpa Pressure
Vertical Conveying Distance
15 m (Chinese Hose)/30 m (Trelleborg Hose)
Horizontal Conveying Distance
40 m (Chinese Hose)/80 m (Trelleborg Hose)
Weight
900kg
Overall Dimension
2350x1250x1450mm

Application of Small Shotcrete Machine

1.    For pumping/grouting/spraying mortar/plaster
2.    For pumping cellular light weight concrete
3.    For pumping of wet normal concrete, acceptable max. aggregate size is 10mm

After-Sales Service of Small Shotcrete Machine
During-sale service of used shotcrete machine
1. Acceptance of the product
2. Assist client product construction scheme

After sale service of Small Shotcrete Machine
1. Spare parts will be delivered as you need.
2. Engineers will go to clients' site for guiding the installation and test-running;
3. Warranty period: 12 months since the installation and commissioning;
