Foton 1.6ton Small Wheel Loader FL917F 1.0cbm Bucket
Evangel Industrial (Shanghai) Co., Ltd.- Type：Universal Type
- Transmission：Hydraulic Transmission
- Walking Mode：Wheeled
- Load and Unload Method：Front Discharge
- Engine Power：74~147kw
- Certification：CE
Base Info
- Model NO.：FL917F
- Condition：New
- Color：Yellow
- L*W*H：5540× 2060× 2870
- Operating Weight：5600kg
- Rated Load：1600
- Bucket Capacity：1cbm
- Transport Package：Nude Packing
- Specification：CE
- Trademark：FOTON
- Origin：Weifang, China
- HS Code：84295100
- Production Capacity：50 Sets,Month
Description
Basic Info.
Model NO. FL917F Condition New Color Yellow L*W*H 5540× 2060× 2870 Operating Weight 5600kg Rated Load 1600 Bucket Capacity 1cbm Transport Package Nude Packing Specification CE Trademark FOTON Origin Weifang, China HS Code 84295100 Production Capacity 50 Sets/MonthProduct Description
FOTON 1.6ton small wheel loader FL917F1. Adopted Model LR4A3-24 engine;
2. Hydro-mechanical transmission avoids the stop due to the sudden increased external load, absorbs and eliminates the vibration and shocks on the engine due to the external load and increases machine life cycle;
3. Four-wheeled driving, low-pressure, wide-base off-highway tires, has a good a performance for passing;
4. Adopted a large vision, all closed damping cab, comfortable operation environment;
| Parameter Items | Parameter Value |
| 1. Main parameter | |
| Rated load( (kg) | 1600 |
| Operating Weight (standard) (kg) | 5600 |
| Rated Bucket Capacity (m3) | 1.0 |
| Maximum breakout force (KN) | 52 |
| Maximum traction force (KN) | 48.6 |
| Total hydraulic cycle (s) | 9 |
| Maximum dump height (mm) | 2415 |
| Maximum dump distance (mm) | 800 |
| Forward speed range (km / h) | 0-26.5 |
| Reverse speed range (km / h) | 0-25 |
| Transport dimensions (L × W × H) (mm) | 5540× 2060× 2870 |
| Maximum steering angle (° ) | 35 |
| Minimum grade ability (° ) | 30 |
| Minimum turning radius (mm) | 4639 |
| Tire Size | 16/70-20-14PR |
| 2. Engine parameter | |
| Model | LR4A3-24 |
| Type | 4-cylinder inline |
| Power (kw) | 55 |
| Maximum torque (N. m) | 256-265 |
| Cylinder diameter (mm) | 105 |
| Stroke (mm) | 125 |
| Output volume (L) | 4.58 |
| Fuel consumption (kw. h) | 243 |
| 3. Hydraulic system | |
| Work system pressure (mpa) | 16 |
| 4. Braking System | |
| Running braking system type | Single pipeline gas-oil 4-wheel clipper disc braking |
| Parking / emergency brake system type | Drum braking |
| 5. Fuel Tank Capacity | |
| Fuel tank (L) | 80 |
| Hydraulic tank capacity (L) | 80 |
