XCMG Gr1603 170HP 13ton China Motor Grader for Sale

XCMG E-Commerce Inc.
  • Certification：Ce,ISO9001
  • Condition：New
  • Applicable Industries：Construction Works
  • Unique Selling Point：Long Lifetime
  • Dimension(L*W*H)：8420*2380*3150mm
  • After-Sales Service Provided：Overseas Service Center Available

Base Info

  • Model NO.：GR1603
  • Warranty：1 Year
  • Engine Brand：Top Brand
  • Forward Speed(Km/H)：47
  • Reverse Speed(Km/H)：30
  • Trademark：XCMG
  • Origin：Jiangsu, China
  • Production Capacity：10000 Unit,Units Per Year

Description

ItemGR1603Basic parametersEngine modelQSB5.9Rated power/speed125kW/2200rpmOverall dimension (standard)8420x2380x3150Total weight (standard)13000kgTire specification13.00-24TG RP12Ground clearance (front axle)654 mmTread2020mmSpace of front and rear axles5780mmPerformance parametersForward velocity5,8,13,18,30,47km/hReverse speed5,13,30km/hTractive effort f=0.7573 kNMaximum gradeability25%Tire inflation pressure260kPaWorking system pressure19MPaTransmission pressure1.3-1.8MpaWorking parametersMaximum steering angle of front wheel±48°Maximum slant angle of front wheel±17°Maximum oscillating angle of front axle±16°Maximum oscillating angle of equilibrium box±15°Maximum steering angle of frame±27°Minimum turning radius6.6mScrape knifeMaximum lift height410mmMaximum cutting depth515mmMaximum tilt angle90°Cutting angle54°-90°Angle of revolution360°Length & chord height3660x610mmOil filling amountCoolant50LFuel tank280LEngine18LTransmission26LBalancing box46LDrive axle28LHydraulic oil96LRelated Products To Choose Online Service Team Company ProfileXCMG Gr1603 170HP 13ton China Motor Grader for SaleXCMG Gr1603 170HP 13ton China Motor Grader for SaleXCMG Gr1603 170HP 13ton China Motor Grader for SaleXCMG Gr1603 170HP 13ton China Motor Grader for SaleXCMG Gr1603 170HP 13ton China Motor Grader for SaleXCMG Gr1603 170HP 13ton China Motor Grader for Sale
