XCMG 215HP Gr2153A China Motor Grader

XCMG E-Commerce Inc.
  • Certification：Ce,ISO9001
  • Condition：New
  • Applicable Industries：Construction Works
  • Unique Selling Point：Long Lifetime
  • Dimension(L*W*H)：8970*2625*3470mm
  • After-Sales Service Provided：Overseas Service Center Available

Base Info

  • Model NO.：GR2153A
  • Warranty：1 Year
  • Engine Brand：Top Brand
  • Forward Speed(Km/H)：38
  • Reverse Speed(Km/H)：23
  • Trademark：XCMG
  • Origin：Jiangsu, China
  • Production Capacity：10000 Unit,Units Per Year

Description

ItemGR2153ABasic parametersEngine modelQSB6.7Rated power/speed164kW/2200rpmOverall dimension (standard)9180x2625x3420Total weight (standard)16100 kgTire specification17.5-25Ground clearance (front axle)430mmSpace of front and rear axles6219 mmSpace of middle and rear wheels1538 mmPerformance
parametersForward velocity5,8,11,19,23,38km/hReverse speed5,11,23km/hTractive effort f=0.75118kNMaximum gradeability30%Tire inflation pressure260kPaWorking system pressure18MPaTransmission pressure1.3-1.8MpaWorking parametersMaximum steering angle of front wheel±50°Maximum slant angle of front wheel±17°Maximum oscillating angle of front axle±15°Maximum oscillating angle of equilibrium boxforwards15°, Reverse15°Maximum steering angle of frame±27°Minimum turning radius7.3mScrape knifeMaximum lift height450mmMaximum cutting depth500mmMaximum tilt angle90°Cutting angle28°-70°Angle of revolution360°Length & chord height4270x610mmOil filling amountCoolant50LFuel tank280LEngine24LTransmission38LEquilibrium box46LDrive alex28LHydraulic oil220LRelated Products To Choose Online Service Team Company ProfileXCMG 215HP Gr2153A China Motor GraderXCMG 215HP Gr2153A China Motor GraderXCMG 215HP Gr2153A China Motor GraderXCMG 215HP Gr2153A China Motor GraderXCMG 215HP Gr2153A China Motor GraderXCMG 215HP Gr2153A China Motor Grader
