5 Ton Wheel Loader with Wood Log Grapple

Shanghai YingXin World Machinery Co., Ltd.
  • After-sales Service：Available
  • Warranty：One Year
  • Certification：ISO, CE, TUV, UL, ISO, CE
  • Condition：New, New
  • Rated Load：3-6t, 3-6t
  • Transmission：Hydraulic - Mechanical, Hydraulic - Mechanical

Base Info

  • Model NO.：W156
  • Load and Unload Mode：Front Discharge, Front Discharge
  • Walking Mode：Wheeled, Wheeled
  • Type：Medium-sized Loader, Medium-Sized Loader
  • Wheel Loader：Loader with Grapple
  • Engine：Cat C6121
  • Gearbox：Zl50 Planet Type
  • Tyre Size：23.5-25
  • Usage：Universal Type
  • Scraper Type：Tractor-Scraper
  • Load and Unload Method：Front Discharge
  • Engine Power：147~515kw
  • Color：Yellow
  • Transport Package：in Container
  • Specification：CE Gost-R ISO
  • Trademark：WORLD
  • Origin：China
  • HS Code：84295100
  • Production Capacity：5000PCS,YEAR

Description

Diesel EngineBrandWeichai Steyr or Cat6121 or CumminsTypeDirect injection, turbocharged, water cooling, 4 strokes, 6 cylindersRated Output (kw)162/162/160Rated Speed (rpm)2200Max. Torque (N.m)855/860/908TransmissionTypePlanet typeRated Input Speed (rpm)2200Transaxle & TireRear Axle OscillationCenter oscillationOscillating Angle Of Rear Axle (°)13Pressure Of Tire (MPa)0.28-0.32Working Hydraulic SystemWorking Pump TypeGear pumpWorking Pressure (MPa)17Lifting Cylinder Bore x Stroke (mm)165x757Tilting Cylinder Bore x Stroke (mm)200x540Steering SystemSteering Pump TypeCBGJ2080Working Pressure (MPa)12Steering Cylinder Bore x Stroke (mm)100x342Max. Steering Angle (°)35
