XCMG 180HP Gr1803 Motor Graders China RC Small Mini Tractor Road Wheel Motor Grader
XCMG E-Commerce Inc.- Certification：Ce,ISO9001
- Condition：New
- Transmission：Hydraulic
- Walking Mode：Wheeled
- Applicable Industries：Construction Works
- Unique Selling Point：Long Lifetime
Base Info
- Model NO.：GR1803
- Dimension(L*W*H)：8900*2625*3470mm
- After-Sales Service Provided：Overseas Service Center Available
- Warranty：1 Year
- Engine Brand：Top Brand
- Forward Speed(Km/H)：38
- Reverse Speed(Km/H)：23
- Trademark：XCMG
- Origin：Jiangsu, China
- Production Capacity：10000 Unit,Units Per Year
Description
ItemGR1803 Basic parameters Engine model SC7H190.1G3 Rated power/speed 140kW/2000rpm Overall dimension (standard) 8900x2625x3420 Total weight (standard) 15400 kg Tire specification 17.5-25 Ground clearance (front axle) 430mm Tread 2156mm Space of front and rear axles 6219 mm Space of middle and rear wheels 1538 mm Performance parameters Forward velocity 5/8/11/19/23/38km/h Reverse speed 5/11/23km/h Tractive effort f=0.75 ≥79 kN Maximum gradeability ≥25% Tire inflation pressure 260kPa Working system pressure 20MPa Transmission pressure 1.3-1.8Mpa Working parameters Maximum steering angle of front wheel ±48° Maximum slant angle of front wheel ±17° Maximum oscillating angle of front axle ±15° Maximum oscillating angle of equilibrium box ±15° Maximum steering angle of frame ±27° Minimum turning radius 7.3m Scrape knife Maximum lift height 400mm Maximum cutting depth 500mm Maximum tilt angle 90° Cutting angle 28°-70° Angle of revolution 360° Length & chord height 3660x610mm Oil filling amount Coolant 50L Fuel tank 280L Engine 24L Transmission 38L Balancing box 46L Drive axle 28L
