• Model NO.：LW1100KV
• Dimension(Long * Breadth * High)：10139X3639X3950mm
• After-Sales Service Provided：Video Technical Support, Online Support
• Hydraulic Pump Brand：Top Brand
• Moving Type：Wheel Loader
• Machine Weight：34000-35000kg
• Engine Brand：Top Brand
• Transport Package：Well
• Specification：standard
• Trademark：XCMG
• Origin：Jiangsu, China
• Production Capacity：10000 Unit,Units Per Year

Overview Product ParametersDescriptionSpecificationUnitRated operating load                11000kgBucket capacity5.5-6.1m³Machine weight34000-35000kgDump clearance at maximum lift3450mmReach at maximum lift1494mmWheel base3700mmTread2450mmMax.breakout force290KnHydraulic cycle time-raise6.6sTotal hydraulic cycle time11.9sMin. turning radius over tyres6306mmArticulation angle40°Gradeability25°Tyre size29.5R25 Overall machine dimension L×W×H10139x3639x3950mmModelQSX15 Rated Power/Speed291/2000kw/rpmTravel speed1-gear(F/R)6.2/6.2km/h2-gear(F/R)11.5/11.5km/h3-gear(F/R)17.5/24.8km/h4-gear(F/R)35.7/-km/hDetailed Photos



Our Advantages
