• Model NO.：722-6
• Engine：Qsb6.7-C220
• Transport Package：Standard Package for Shipment
• Specification：ISO
• Trademark：Changlin
• Origin：Jiangsu, China
• HS Code：84295100
• Production Capacity：600 PCS,Month

Overall Dimension
1
Length
9190mm
2
Width
2600mm
3
Height(To the top of the cab)
3600mm
4
Wheel base
6100mm
5
Tread
2120(mm)
Main Technical Specification
1
Operating weight
16400kg
2
Blade length
4320mm
3
Blade height
645mm
4
Blade width
22mm
5
Max lifting height
450mm
6
Max grading depth
535mm
7
Min. turning radius
7300mm
8
Pivot angle frame
+260
9
Max turning angle(front wheel)
+490
10
Oscillating angle of front axle
320
11
Front axle center ground clearance
610mm
12
Cut angle
29-77°
13
Traveling speed(Km/h),6 forward and 3 reverse


(1) 1 gear forward
6.8

(2) 2 gear forward
10.3

(3) 3 gear forward
15.3

(4) 4 gear forward
22.7

(5) 5 gear forward
32

(6) 6 gear forward
47

(7) 1 gear reverse
6.8

(8) 2 gear reverse
15.3

(9) 3 gear reverse
32
Diesel Engine
1
Model
QSB6.7-C220
2
Type
Direct injection. Turbocharged. Water cooling
3
Rated output
164 kW
4
Inter-bore of cylinder/Stroke
107/124  (mm)
5
Total exhaust of cylinder
6.7 (L)
6
Model of starting motor
KB-24V
7
Power of start motor
1.68(KW)
8
Voltage of starting motor
24(V)
9
Rated speed
2200(r/min)
10
Max. Torque
>800(N.M)
11
Starting type
Electric
12
Min. specific fuel consumption
<244(g/Kw.h)
13
Engine specific oil consumption
0.95-1.77(g/Kw.h)
14
Net weight
590(kg)
