• Model NO.：Liugong Hzs60
• Vibrating Amplitude：2.4mm
• Certification：ISO9001: 2000, CE
• Condition：New
• Color：Green
• Model No.：Hb37c
• Reach Height：37m
• Chassis：Isuzu,Volvo,Benz
• Demension：12080*2490*3990mm
• Emission：Euro III
• Transport Package：Nude
• Specification：CE, RoHS, SGS, GMP
• Trademark：XCMG
• Origin：Jaingsu China
• HS Code：84295100
• Production Capacity：50, 000 PCS,Year.

Basic Info.

Model NO. Liugong Hzs60 Vibrating Amplitude 2.4mm Certification ISO9001: 2000, CE Condition New Color Green Model No. Hb37c Reach Height 37m Chassis Isuzu/Volvo/Benz Demension 12080*2490*3990mm Emission Euro III Transport Package Nude Specification CE, RoHS, SGS, GMP Trademark XCMG Origin Jaingsu China HS Code 84295100 Production Capacity 50, 000 PCS/Year.

Product Description

1. Concrete productivity: 60M3/H
2. 3*15M3 Aggregate storage hopper




AGGREGATE STATION

Aggregate storage hopper 3*15M3

Material weighing hopper 2T

Thickness of the steel used δ 4

Load-cell 4*2000kg

Belt 650mm

KAIFENG YULONG

Belt conveyor loading capacity 300T/h

Electrical roller ZHEJIANG XINGHE/JIANGSU TAILONG 1*11kw

Vibrator MVE200/3 quantity 2

SLOPE BELT CONVEYOR

Belt 650mm

Belt conveyor loading capacity 450t/h

Electric roller: 15KW

Steel thickness of the frame L50*5mm, L63*6mm

Belt tilt angle 20.

MIXER

Mixer model SICOMA

Mixer type MSO1500/1000

Mixer capacity per batch 1000L

Mixer discharge control Hydraulic control

Mixer driving motor 2*18.5

Water discharge pump connected to the mixer: NO

WATER WEIGHING SYSTEM

Water charging pump Shanghai GUOTAI

GISG65-125 3KW

Water weighing hopper 200KG

Pneumatic butterfly valve Shanghai GUOTAI

DN50

Load-cell AMCELLS 500KG

ADDITIVE WEIGHING SYSTEM

Additive charging pump Shanghai GUOTAI GIHG32-125 0.75KW

Additive weighing hopper 30KG

Pneumatic butterfly valve Shanghai GUOTAI DN50

Load-cell AMCELLS 100KG

Additive container capacity
