• Model NO.：8105HL
• Certification：ISO 9001:2000, ISO 9001:2008
• Condition：New
• Operating Weight：10 Ton
• Theoretical Gradeability：40%
• Power：82kw
• Static Line Load：235n,Cm
• Transport Package：Seaworthy Packing
• Specification：ISO
• Trademark：Changlin
• Origin：Jiangsu, China
• HS Code：37418526
• Production Capacity：60000 PCS,Month

Basic Info.

Model NO. 8105HL Certification ISO 9001:2000, ISO 9001:2008 Condition New Operating Weight 10 Ton Theoretical Gradeability 40% Power 82kw Static Line Load 235n/Cm Transport Package Seaworthy Packing Specification ISO Trademark Changlin Origin Jiangsu, China HS Code 37418526 Production Capacity 60000 PCS/Month

Product Description

 Changlin Hydraulic Double Drum Roller Vibratory Roller 10 Ton


Double steel drum hydraulic vibrating road roller adopts the international advanced technology and its key components are imported from abroad. This machine is mainly applied into the pavement engineering from compacting various materials such as stabilized soil, asphalt concrete and hard concrete. It is also suitable for the subgrade works and is an ideal compacting machine for building high-grade highway, railway, airport, dam, municipal roads and industrial ground.

Features
1. Thus road roller adopts Cummis B series watercooled diesel engine with high coefficient of power reserve
2. The compactor type engineering vehicle is powered by hydro static, allwheel drive system and can perform stepless speed changing in two ranges.

3. Our double steel drum hydraulic vibrating road roller is equipped with the dual band and double amplitude vibration device, the imported plunger pump and motor

4. There is a built in wet multiple disc brake used to brake in emergency circumstances by fuel cut off, which greatly improves the operation safety and reliability.

5. Its streamline design makes the whole car appear more attractive.


Specifications
Operating Mass: 10000kg
Static Line Load: 235N/cm
Vibration Amplitude: 0.74/0.35mm
Vibration Frequency: 40/50HZ
Centrifugal Force: 115*2/ 85*2kN
Traveling speed: 13 (km/h)
Gradient capacity: 40%
Turning Radius: 7000mm
Drum Width: 2130mm
Drum Diameter: 3368mm
Ground Clearance: 320mm
Diesel Engine Model: 4BTA3.9
Diesel Engine Power: 82Kw
Ovewall Dimensions: 5360*2270*2970
