• Model NO.：RDJ90
• Certification：ISO9001: 2000, CE
• Condition：New
• Power：265.52kw
• Transport Package：Standard Package for Shipment
• Specification：ISO
• Trademark：ROADY
• Origin：Jiangsu, China
• HS Code：84743200
• Production Capacity：10 PCS,Month

Technical SpecificationRDJ90Rated capacity90t/hCold hopper quantity4Cold hopper volume6.5m³Standard burnerOil burnerOil Consumption6.5kg/tScreen 4 layersMixer capacity1000kg/batchPowder temporary storage capacity1.8m³New filler silo22m³Old filler silo12.5m³Finished warehouse capacity-Asphalt tank1×40 m³Heavy oil tanks-Light oil tanks-hot oil stove3x104The total installedpower265.52kWDimenSion32m×27m×16m


Modular cold aggregate feeding system which can synchronization proportional control and adjust automaticly
Energy-efficient dry heating systems whose heat exchange efficiency reach 90%
High-strength plate chain bucket elevator system with 0 db mute backstop
Quick changing and maintenance-free screening system with smart air lead and pressure relief
High precision weighing system with good stability and automatically error compensation
High efficiency and large-circulation stereo boiling mixing system with 15% overcapacity redundant design
Efficient and environmentally friendly bag filter system with emissions Far exceeding the national standards
Stackedfiller silo with customized items available, reclaimed filler re-using system
Asphalt supply system with easy and flexible combination and fast installation
High reliability air system which can continuous working in extreme environment with -15ºC-50ºC
Stable and easy operationPC+PLC smart control system with independent intellectual property rights
