• Model NO.：R215-7C
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000
• Condition：New
• Engine Model：Cummins B5.9-C
• Rated Power：110kw
• Operating Weight：20700kg
• Overall Dimension(L*W*H)：9510*2990*2880mm
• Transport Package：Nude Package
• Specification：ISO, CE, GOST
• Trademark：Hyundai
• Origin：China(Mainland), Jiangsu
• Production Capacity：1500 Units, Year

Basic Info.

Model NO. R215-7C Size Medium-Sized Certification CE, ISO9001: 2000 Condition New Engine Model Cummins B5.9-C Rated Power 110kw Operating Weight 20700kg Overall Dimension(L*W*H) 9510*2990*2880mm Transport Package Nude Package Specification ISO, CE, GOST Trademark Hyundai Origin China(Mainland), Jiangsu Production Capacity 1500 Units/ Year

Product Description

Hyundai brand 21 ton Hyundai Excavator(R215-7C)

Specification:
Operation Weight: 20700kg
Bucket Capacity: 0.92m³
Engine Model: Cummins B5.9-C
Engine Power: 112kw/150HP
Travel Speed: 3.5-5.2km/hr
Swing Speed: 12.5rpm
Grade Ability: 35degree
Operation Modth: CAPO computer-controlled, self-diagnostic system.
Hydraulic system
Working pressure 300Kgf/cm2
Max. Flow 2*220L/min
Performance
Max. Digging force(bucket) 13500kgf
Max. Digging force(jib) 9700kgf
Max. Traction 19500kgf
Dimensions
Boom Length: 5650mm
Stick Length: 2920mm
Crawler ground length: 3360mm
Crawler length: 4160mm
Counter weight ground clearance: 060mm
Tail radius of gyration: 2830mm
Total length: 9510mm
Gauge: 2200mm
Total height: 2990mm
Overall width: 2800mm
Track shoe width: 600mm

Operating range
Max. Effective range of mining: 9930mm
Max. Digging depth: 6800mm
Max. Vertical digging depth: 6060mm
Max. Digging height: 9730mm
Max. Dumping height: 6910mm
Minimum radius of gyration: 3440m
