| Manufacturer | XGMA |
| Model | XG953H |
| Overall length(mm) | 7710 |
| Overall height(mm) | 3450 |
| Overall width(mm) | 2880 |
| Wheel base(mm) | 2880 |
| Ground clearance(mm) | 500 |
| Tread(mm) | 2240 |
| Bucket Width (mm) | 3000 |
| Turn radius(mm) | 5775 |
| Min.Turn radius outside of bucket (mm) | 6650 |
| | 4120 |
| Max. Dumping Height(mm) | 3215 |
| Dumping Reach(mm) | 1185 |
| Digging depth(mm) | 80 |
| | 47 |
| | | |
| Engine model | SC9D220G2B1/SC11CB220G2B1/6CTA8.3-C125/WD615 |
| Rated power (kw) | 162/162/160/162 |
| Fuel comsumption per hour(g/kw.h ) | 220/225/229/205 |
| Rated speed (r/min) | 2200/2200/2200/2200 |
| Max torque(N.m) | 880/844/908/850 |
| Operating Weight (Tonnes) | 17.2 |
| Rated Load(Tonnes) | 5 |
| Bucket capacity (m3) | 2.2-3.6 |
| Lifting time/Lifting, dumping and lowering(s) | 5.8/11 |
| Max Breakout force(KN) | 170 |
| Max. turning angle(°) | ±35° |
| Fuel tank(L) | 220 |
| Hydraulic tank(L) | 295 |
| Working pressure of steering hydraulic system(MPa) | 15 |
| Working pressure of load hydraulic system(MPa) | 16 |
| Travel speeds(km/h) | FORWARD 1ST | 0~11.5 |
| FORWARD 2ND | 0~38 |
| FORWARD 3RD | - |
| FORWARD 4TH | - |
| REVERSE 1ST | 0~16 |
| REVERSE 2ND | - |
| REVERSE 3RD | - |
| Gear Box | XG |
| Axle | XG |
| Implement pump | 209 |
| Distibuting valve | D32 |
| Steering Hydraulic system | BZZ6-1000 |
| Steering pump | 143 |
| Tyre size | 23.5-25-16PR |
| Air Conditioning/Anti-mist when idleing | √ |
| Heating | √ |
| Radio/Cassette | √ |
| Bucket and arm raiseing (limit height) Device | √ |
| Hydraulic Operation system | √ |
| Electricial Monitor and alarm system | √ |
| Seat Buckle | √ |
| Head lamp | √ |
| Reversing Alarm (Back vehicle) | √ |
