• Model NO.：R225LC-7
• Size：Medium-Sized
• Certification：CE, ISO9001: 2000
• Condition：New
• Operating Weight：22100kg
• Engine：Cummins
• Engine Power：112kw
• Digging Distance：9940mm
• Transport Package：Nude Package
• Specification：CE, ISO, GHOST
• Trademark：HYUNDAI
• Origin：Jiangsu, China
• Production Capacity：5000sets, Month

Basic Info.

Model NO. R225LC-7 Size Medium-Sized Certification CE, ISO9001: 2000 Condition New Operating Weight 22100kg Engine Cummins Engine Power 112kw Digging Distance 9940mm Transport Package Nude Package Specification CE, ISO, GHOST Trademark HYUNDAI Origin Jiangsu, China Production Capacity 5000sets/ Month

Product Description

Hot sale new Hyundai hydraulic crawler excavator R225LC-7 22ton excavator

1.Cummins Engine crawler excavator 22ton
2.Hyundai brand
3.Originally imported motor and pump
4.Parts
China Hydraulic Crawler Excavator - Hyundai Excavator Price 22 ton - Hyundai 220 Excavator

Hyundai excavator 22ton  R225LC-7
Weight:22100KG
Bucket:092m3

Engine:
Model:B5.9-C
Rated Power:112/1950KW/rpm
Max torque:62.6/1500kgf.m/rpm

Hydraulic systme:
Working pressure:330kgf/cm2
Max. flow:2*220L/min

Performance
Swing Speed:12,5 rpm
Travel Speed:5.3/3.4 km/h
Max.digging force(bucket)              15500kgf
Max.digging force(jib)                  12000kgf
Grade Ability:                          35degree
Max. Traction                          21100kgf

Specification:
A-Crawler Length:                            4440mm
B-track ground length:                        3650mm
C-Stick length:                               2390mm
D-Track shoe width:                           600mm
E-Min.ground clearance:                       480mm

Oil Tank :                 320L
Hydraulic tank:             180L

Dimensions
F-Total length:                                                 9650mm
G-Overall width:                                                2990mm
H- Total height:                                                 3200mm
I- Counter weight ground clearance:                 1060 mm
J- Tail length                              2770mm
K-Up width                               2700mm
L-Cabin Height                            2920mm
J'- Tail radius of gyration:                                  2830mm

Operating range
A.Max. Digging distance:                    9940mm
