Hydraulic Crawler Excavators Xe215cll
Oriemac Machinery & Equipment (Shanghai) Co., Ltd.- Type：Crawler Excavator
- Usage：Marine Excavator
- Bucket：Shovel
- Transmission：Hydraulic Transmission
- Drive Type：Internal Combustion Drive
- Bucket Capacity：0.1~0.5m³
Base Info
- Model NO.：XE215CLL
- Size：Medium-Sized
- Certification：CE, ISO9001: 2000, GOST
- Condition：New
- Color：Yellow
- Transport Package：Nude, Suitable for Shiping
- Specification：ISO
- Origin：Jiangsu, China
- HS Code：8701100000
- Production Capacity：100 Sets,Month
Description
ModelUnit X E215CLL Operating weight kg 22350 Standard bucket capacity m³ 0.5 Engine Engine Model / ISUZU BB-6BG1TRP Direct injection / √ Four strokes / √ Water cooling / √ Turbo charged / √ Air to air intercooler / × No. of cylinders / 6 Rated power/speed kw/rpm 106.5/1950 Max. torque/speed N.m 551/1600 Displacement L 6.494 performance Travel speed km/h 5.5/ 2.8 Swing speed r/min 12.2 Max. gradeability / ≤35 Ground pressure kPa 36.2 Max.Bucket digging force kN 78.7 Max.arm crowd force kN 40 Max.traction force kN 179 hydraulic system Main pump / 2 Rate flow of main pump L/min 2×206 Max pressure of prime relief valve MPa 32.3/34.3 Max pressure of travel system MPa 34.3 Max pressure of swing system MPa 28 Max pressure of pilot system MPa 3.9
